Rigol
Rigol DS2102A-S
100 MHz, 2 Channel Digital Oscilloscope with integrated 2 channel source
100 MHz Bandwidth
2 Analog Channels Channels
2 GSa/s Sample Rate
56 Mpts (standard) Memory Depth
8-bit Vertical Resolution
| Attribute | Value |
|---|---|
| Bandwidth | 100 MHz |
| Channels | 2 Analog Channels |
| Sample Rate | 2 GSa/s |
| Memory Depth | 56 Mpts (standard) |
| Vertical Resolution | 8-bit |
| Display | 8-inch WVGA (800 x 480) TFT LCD |
| Waveform Capture Rate | Up to 50,000 wfms/s |
| Included Probes | 2 x RP2200 Passive Probes (200 MHz) |
| Connectivity | USB Host, USB Device, LAN (LXI), Aux Output |
| Trigger Types | Edge, Pulse, Runt, Windows, Nth Edge, Slope, Video, Pattern, Delay, Timeout, Duration, Setup/Hold, RS232, I2C, SPI |
| Model | DS2102A-S |
|---|
The DS2000A series digital oscilloscope is another Best-In-Class instrument from Rigol offering an unmatched feature/value package. The DS2000A is a fast and versatile scope covering frequencies up to 300 MHz with two channels and a wide vertical range (500uV/div-10V/div) to deliver an extremely low noise floor to help you capture smaller signals. Add a 2 GSa/s max. sample rate and 14 Mpts. of standard memory depth to its user-friendly interface and 8 inch WVGA display and you've got a scope that outperforms the competition in a wide range of bench-top and field applications.
