Rohde & Schwarz NRP6AN
Average Power Sensor - 100 pW to 200 mW, 8 kHz to 6 GHz, LAN version
10 MHz to 6 GHz Frequency Range
-60 dBm to +20 dBm Power Measurement Range
N-Type (female) Connector Type
±0.9 dB (typical) Measurement Uncertainty
USB Interface
| Attribute | Value |
|---|---|
| Frequency Range | 10 MHz to 6 GHz |
| Power Measurement Range | -60 dBm to +20 dBm |
| Connector Type | N-Type (female) |
| Measurement Uncertainty | ±0.9 dB (typical) |
| Interface | USB |
| Impedance | 50 Ω |
| Sensor Technology | Three-path diode power sensor |
| Operating Temperature Range | 0 °C to +55 °C |
| VSWR (Maximum) | 1.15 (typical, frequency dependent) |
| Compatible Instruments | Rohde & Schwarz NRP2, NRPZ, and NRP-Z Base Units; also PC-controlled via USB |
Rohde & Schwarz NRP6AN Options:
- NRP6AN - NRP-Z4 - USB adapter cable (passive)
- NRP6AN - NRP-Z3 - USB adapter cable (active)
- NRP6AN - NRPZ-K1 - R&S NRPV license for one sensor
- NRP6AN - NRP-Z5 - Sensor hub
| Model | NRP6AN |
|---|
The Rohde & Schwarz NRP6AN is a high-precision average power sensor that supports RF measurements from 8 kHz to 6 GHz, utilizing advanced three-path diode technology for high accuracy. It offers wide dynamic range from –70 dBm to +23 dBm.
Engineered for EMC testing, telecom, and industrial setups, it features LAN with PoE and USB connectivity, a built-in web GUI, and complies with standards like IEC/EN 61000‑4‑3 and MIL‑STD‑461.
Testwall can supply the used Rohde & Schwarz NRP6AN, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Rohde & Schwarz NRP6AN.
