Rohde & Schwarz SMZ90
| Attribute | Value |
|---|---|
| Frequency Range | 60 GHz to 90 GHz |
| Output Power (typical) | -10 dBm to +5 dBm |
| Harmonic Suppression | > 20 dBc |
| Input Frequency Range | 10 GHz to 15 GHz |
| RF Connector Type | WR-12 Waveguide (UG-387/U Flange) |
| Input Connector | 2.92 mm (K) female |
| Multiplication Factor | x6 |
| Compatible Signal Generators | Rohde & Schwarz SMF100A, SMB100A, SMA100A |
| Operating Temperature Range | 0°C to +50°C |
| Power Supply | Supplied via connected signal generator (no external power required) |
Rohde & Schwarz SMZ90 Options:
- SMZ90 - SMZ-B90M - Mechanically Controlled Attenuator for the R&S SMZ90
- SMZ90 - SMZ-B90E - Electronically Controlled Attenuator for the R&S SMZ90
- SMZ90 - SMZ-K1 - Software License for external PC software
| Model | SMZ90 |
|---|
The Rohde & Schwarz SMZ90 Frequency Multiplier features a 10–15 GHz input and 60–90 GHz output range, delivering precise signal multiplication. Input levels range from +6.7 to +7.3 dBm, and output ranges from –25 dBm to +10 dBm with adjustable attenuation. It is compatible with R&S SMF100A and SMB100A signal generators for seamless integration and advanced functionality.
Perfect for R&D, telecom, and radar applications, the SMZ90 ensures stable, high-frequency signal generation with a compact form factor and USB connectivity for easy operation.
Testwall can supply the used Rohde & Schwarz SMZ90 Frequency Multiplier, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Rohde & Schwarz SMZ90 Frequency Multiplier.
