Rohde & Schwarz ZNBT40
| Attribute | Value |
|---|---|
| Frequency Range | 100 kHz to 40 GHz |
| Number of Ports | Up to 24 ports (scalable) |
| Dynamic Range | >140 dB |
| Output Power | +10 dBm (max) |
| Measurement Speed | 4 ms per point (typical) |
| Trace Noise | <0.004 dB RMS |
| Port Impedance | 50 Ohm |
| Connector Type | 2.92 mm (K) female |
| Operating System | Windows 10 Embedded |
| Interface | LAN (1 Gbit/s), USB 3.0, GPIB (optional) |
Rohde & Schwarz ZNBT40 Options:
- ZNBT40 - B112 - Adds Ports 9 to 12
- ZNBT40 - B116 - Adds Ports 13 to 16
- ZNBT40 - B120 - Adds Ports 17 to 20
- ZNBT40 - B124 - Adds Ports 21 to 24
- ZNBT40 - B21 - Extended Power Range, Ports 1 to 4
- ZNBT40 - B22 - Extended Power Range, Ports 5 to 8
- ZNBT40 - B23 - Extended Power Range, Ports 9 to 12
- ZNBT40 - B24 - Extended Power Range, Ports 13 to 16
- ZNBT40 - B25 - Extended Power Range, Ports 17 to 20
- ZNBT40 - B26 - Extended Power Range, Ports 21 to 24
- ZNBT-B4 - Precision Frequency Reference (OCXO)
- ZNBT-B10 - GPIB Interface
- ZNBT-B12 - Device Control
- ZNBT-B19 - Additional Removable SSD, 64 bit
- ZNBT-B81 - DC Inputs
- ZNBT-K2 - Time Domain Analysis
- ZNBT-K4 - Frequency Conversion
- ZNBT-K14 - Intermodulation Measurements
- ZNBT-K17 - 10 MHz Receiver Bandwidth
- ZNBT-K19 - 1 mHz Frequency Resolution
- ZNBT-K20 - Extended Time Domain Analysis
- ZNBT-Z14 - Handler I/O (External)
| Model | ZNBT40 |
|---|
The Rohde and Schwarz ZNBT40 is a powerful network analyzer platform extension supporting up to 24 ports and a frequency range of 100 kHz to 40 GHz. It offers fast sweep speeds, an impressive 140 dB dynamic range, and minimal signal loss via its 24-port architecture without switching. Advanced calibration techniques enable precise multiport measurements.
Perfect for evaluating dense RF front-ends, the ZNBT40 excels in high-throughput multiport testing environments where accuracy and speed are critical.
Testwall can supply the used Rohde and Schwarz ZNBT40, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Rohde and Schwarz ZNBT40.
