Rohde & Schwarz
Rohde & Schwarz CBT
Bluetooth Tester
87.5 MHz to 108 MHz (FM Band) Frequency Range
Audio analyzer, RF analyzer, RDS analyzer, and Bluetooth test capabilities Measurement Functions
Up to 10 dBm (adjustable) RF Output Power Range
20 Hz to 100 kHz Audio Frequency Range
Less than 0.01% Total Harmonic Distortion (THD)
| Attribute | Value |
|---|---|
| Frequency Range | 87.5 MHz to 108 MHz (FM Band) |
| Measurement Functions | Audio analyzer, RF analyzer, RDS analyzer, and Bluetooth test capabilities |
| RF Output Power Range | Up to 10 dBm (adjustable) |
| Audio Frequency Range | 20 Hz to 100 kHz |
| Total Harmonic Distortion (THD) | Less than 0.01% |
| Signal-to-Noise Ratio (SNR) | Greater than 80 dB |
| Interface/Connectivity | USB, GPIB, LAN (LXI compliant) for remote control and data transfer |
| Display | Built-in color TFT display for real-time measurement results |
| Power Supply | 100 V to 240 V AC, 50/60 Hz |
| Operating Temperature Range | 0°C to 40°C (32°F to 104°F) |
| Model | CBT |
|---|
The Rohde & Schwarz CBT executes high-speed Bluetooth® RF testing, integrating power, modulation, frequency, and BER tests in a single cycle. Spectrum measurements are performed without an external analyzer.
Supports Bluetooth® core specifications 1.2 to 4.0 with options for EDR and low energy tests. Ideal for production and R&D with real-time traces and R&S®CBTGo software compatibility.
Testwall can supply the used Rohde & Schwarz CBT, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Rohde & Schwarz CBT.
