Rohde & Schwarz ESHS30
| Attribute | Value |
|---|---|
| Frequency Range | 9 kHz – 30 MHz |
| Impedance | 50 Ω / 150 Ω (switchable) |
| Maximum Continuous Voltage (DC) | 250 V DC |
| Maximum Continuous Current | 25 A |
| Insertion Loss | < 1 dB (typical) |
| Voltage Division Factor | 32 dB (at 50 Ω) / 10 dB (at 150 Ω) |
| Connector Type | BNC (RF output), screw terminals (line connection) |
| Standards Compliance | CISPR 16-1-2, EN 55016-1-2 |
| Operating Temperature Range | 0 °C to +55 °C |
| Dimensions (W × H × D) | Approximately 220 mm × 90 mm × 270 mm |
Rohde & Schwarz ESHS30 Options:
- ESHS30 - ENY4-B1 - 3 additional RJ45 adapter sets for ENY41
| Model | ESHS30 |
|---|
The Rohde & Schwarz ESHS30 is a double-conversion heterodyne receiver with a frequency range of 9 kHz to 30 MHz, offering precise level measurements from -36 to +137 dBµV and fine 10 Hz resolution. It includes five preselection filters, parallel detectors for various signal types, and complies with CISPR 16-1, VDE 0876, and ANSI C63.2 standards.
Ideal for EMC testing, the ESHS30 supports both battery and AC power, features automatic test macros, and ensures compatibility with standards such as ETS, FCC, VCCI, and VDE 0871–0879.
Testwall can supply the used Rohde & Schwarz ESHS30, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Rohde & Schwarz ESHS30.
