Rohde & Schwarz FSH6 (Model .26)
| Attribute | Value |
|---|---|
| Frequency Range | 100 kHz to 6 GHz |
| Display | 6.5-inch color TFT LCD (640 x 480 pixels) |
| Dynamic Range | Up to 100 dB |
| Resolution Bandwidth (RBW) | 100 Hz to 3 MHz |
| Phase Noise | -95 dBc/Hz at 10 kHz offset (typical) |
| DANL (Displayed Average Noise Level) | -144 dBm (typical, with preamplifier) |
| Battery Operating Time | Approximately 3 hours with standard battery pack |
| Weight | Approximately 3.3 kg (7.3 lbs) including battery |
| Input Impedance | 50 Ohms |
| Operating Temperature Range | -10°C to +55°C (14°F to 131°F) |
Rohde & Schwarz FSH6 (Model .26) Options:
- FSH6 - FSH-B1 - Distance-to-Fault Measurement (includes 1 m cable, R&S FSH-Z2 required)
- FSH6 - FSH-K1 - Remote Control via RS-232-C
- FSH6 - FSH-K2 - Vector Transmission and Reflection Measurements
- FSH6 - FSH-K3 - Receiver Mode
| Model | FSH6 |
|---|
The R&S FSH6.26 is a robust handheld spectrum analyzer covering 100 kHz to 6 GHz, with a built-in preamplifier and tracking generator. It delivers a displayed average noise level of -135 dBm (RBW 100 Hz) and features a dynamic range of 90 dB for precise vector transmission measurements. Its level accuracy is typically 0.5 dB up to 6 GHz and supports resolution bandwidths from 100 Hz to 1 MHz.
This model is ideal for field applications, integrating various detector modes including RMS, peak, and auto peak. The tracking generator spans 5 MHz to 6 GHz for versatile signal tracing capabilities.
Testwall can supply the used R&S FSH6.26, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the R&S FSH6.26.
