Rohde & Schwarz FSP7
| Attribute | Value |
|---|---|
| Frequency Range | 9 kHz to 7 GHz |
| Resolution Bandwidth | 10 Hz to 10 MHz |
| Display Average Noise Level | -145 dBm (typical, at 1 GHz, 0 dB attenuation) |
| Phase Noise | < -98 dBc/Hz at 10 kHz offset (at 1 GHz carrier) |
| Total Amplitude Accuracy | < 0.5 dB (typical) |
| Input Impedance | 50 Ohm |
| Maximum Input Level | +30 dBm (1 W) continuous |
| Dynamic Range | > 100 dB (third-order intercept point) |
| Video Bandwidth | 1 Hz to 10 MHz |
| Reference Level Range | -130 dBm to +30 dBm |
Rohde & Schwarz FSP7 Options:
- FSP7 - B1 - Cabinet for portable use
- FSP7 - B3 - AM/FM audio demodulator
- FSP7 - B4 - OCXO reference frequency
- FSP7 - B6 - TV trigger/RF power trigger
- FSP7 - B9 - Tracking generator
- FSP7 - B10 - External generator control
- FSP7 - B15 - Pulse calibrator
- FSP7 - B16 - LAN interface
- FSP7 - B20 - Extended environmental specification
- FSP7 - B21 - LO/IF ports for external mixers
- FSP7 - B25 - Electronic attenuator
- FSP7 - B28 - Trigger port
- FSP7 - B29 - Frequency range extension 20 Hz
- FSP7 - B30 - DC power supply
- FSP7 - B31 - Battery pack
- FSP7 - B32 - Spare battery pack
- FSP7 - B70 - Demodulation hardware memory extension
- FSP7 - FS-K4 - Phase noise measurements (Windows software)
- FSP7 - FS-K5 - Modulation and spectrum measurements on GSM/EDGE base station and mobile signals
- FSP7 - FS-K7 - AM/FM/φM measurement demodulator for general applications
- FSP7 - FS-K8 - Bluetooth transmitter measurements
- FSP7 - FS-K9 - Power sensor measurements
- FSP7 - FS-K72 - Modulation and code domain power measurements in accordance with 3GPP TS 24.141 on base station signals (Node B)
- FSP7 - FS-K73 - Modulation and code domain power measurements in accordance with 3GPP TS 25.121 on mobile station signals (UE)
- FSP7 - FS-K74 - HSDPA extension for R&S FS-K72
- FSP7 - FS-K76 - Modulation and code domain power measurements on TD-SCDMA base station signals
- FSP7 - FS-K77 - Modulation and code domain power measurements on TD-SCDMA mobile station signals (UE)
- FSP7 - FS-K82 - Modulation and code domain power measurements in accordance with CDMA2000/1xEV-DV on base station signals
- FSP7 - FS-K83 - Modulation and code domain power measurements on CDMA2000/1xEV-DV mobile station signals (UE)
- FSP7 - FS-K84 - Modulation and code domain power measurements on 1xEV-DO base station signals
- FSP7 - FS-K85 - Modulation and code domain power measurements on 1xEV-DO mobile station signals (UE)
- FSP7 - FSP-K90 - WLAN 802.11a Application Firmware
- FSP7 - FS-K30 - Noise figure measurements (application firmware), remote-controllable
| Model | FSP7 |
|---|
The Rohde & Schwarz FSP7 Spectrum Analyzer covers a frequency range from 9kHz to 7GHz with a -140dBm noise floor, 10Hz–10MHz RBW including EMI bandwidths, and 0.5dB total measurement uncertainty. It features a 21cm TFT color display, largest in its class, and integrates selective digital filters, FFT, and quasi-peak detectors.
Designed for advanced RF analysis, the FSP7 supports ACP, multicarrier ACP, TOI, OBW, and gated sweep for TDMA signal testing, with USB, GPIB, RS-232-C, and optional LAN interfaces.
Testwall can supply the used Rohde & Schwarz FSP7, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Rohde & Schwarz FSP7.
