Rohde & Schwarz RTO2024 Digital oscilloscope
Digital oscilloscope,? 4 channels, 2GHz bandwidth, sampling rate 10GSa/s per channel,? sampling memory 50MSa per channel
200 MHz Bandwidth
4 Number of Channels
4 Gsample/s Sample Rate
200 Mpoints (standard), upgradeable to 800 Mpoints Memory Depth
8 bit (up to 16 bit with High Definition mode) Vertical Resolution
| Attribute | Value |
|---|---|
| Bandwidth | 200 MHz |
| Number of Channels | 4 |
| Sample Rate | 4 Gsample/s |
| Memory Depth | 200 Mpoints (standard), upgradeable to 800 Mpoints |
| Vertical Resolution | 8 bit (up to 16 bit with High Definition mode) |
| Display | 10.4-inch capacitive touchscreen, 1024 x 768 resolution |
| Waveform Update Rate | Up to 1,000,000 waveforms/second |
| Time Base Range | 25 ps/div to 10,000 s/div |
| Input Impedance | 1 MΩ || 13 pF / 50 Ω |
| Connectivity & Interfaces | USB, LAN (LXI), HDMI, optional GPIB |
Rohde & Schwarz RTO2024 Digital oscilloscope Options:
- RTO2024 - RTO-B1 - Mixed Signal Option, 400 MHz (additional 16 logic channels)
- RTO2024 - RTO-B4 - OCXO 10 MHz (precision reference frequency with reference input and output connectors)
- RTO2024 - RTO-B6 - Arbitrary Waveform Generator, 100 MHz, 2 analog channels, 8-bit pattern generator
- RTO2024 - RTO-B10 - GPIB Interface
- RTO2024 - RTO-B19 - Additional Solid State Disk
- RTO2024 - RTO-B101 - Memory Upgrade, 100 Msample per channel
- RTO2024 - RTO-B102 - Memory Upgrade, 200 Msample per channel
- RTO2024 - RTO-B104 - Memory Upgrade, 400 Msample per channel
- RTO2024 - RTO-B110 - Memory Upgrade, 1 Gsample per channel
- RTO2024 - RTO-B223 - Upgrade of the RTO2022/4 to 3 GHz bandwidth
- RTO2024 - RTO-B224 - Upgrade of the RTO2022/4 to 4 GHz bandwidth
- RTO2024 - RTO-B226 - Upgrade of the RTO2024 to 6 GHz bandwidth
- RTO2024 - RTO-K1 - I2C/SPI Serial Decoding
- RTO2024 - RTO-K2 - UART/RS-232/RS-422/RS-485 Serial Decoding
- RTO2024 - RTO-K3 - CAN/LIN Serial Triggering and Decoding
- RTO2024 - RTO-K4 - FlexRay Serial Triggering and Decoding
- RTO2024 - RTO-K5 - I2S Serial Triggering and Decoding
- RTO2024 - RTO-K6 - MIL-STD-1553 Serial Triggering and Decoding
- RTO2024 - RTO-K7 - ARINC 429 Serial Triggering and Decoding
- RTO2024 - RTO-K8 - Ethernet Serial Decoding
- RTO2024 - RTO-K9 - CAN-FD Serial Triggering and Decoding
- RTO2024 - RTO-K10 - SENT Serial Triggering and Decoding
- RTO2024 - RTO-K11 - I/Q Software Interface
- RTO2024 - RTO-K12 - Jitter Analysis
- RTO2024 - RTO-K13 - Clock Data Recovery
- RTO2024 - RTO-K17 - High Definition Mode
- RTO2024 - RTO-K18 - Spectrum Analysis
- RTO2024 - RTO-K19 - Zone Trigger
- RTO2024 - RTO-K21 - USB 2.0 Compliance Test
- RTO2024 - RTO-K22 - Ethernet Compliance Test (10/100/1000BASE-T)
- RTO2024 - RTO-K23 - Ethernet Compliance Test (10GBASE-T)
- RTO2024 - RTO-K24 - BroadR-Reach (100BASE-T1) Compliance Test
- RTO2024 - RTO-K25 - Ethernet Compliance Test (2.5G/5G-BASE-T)
- RTO2024 - RTO-K26 - MIPI D-PHY Compliance Test
- RTO2024 - RTO-K31 - Power Analysis
- RTO2024 - RTO-K40 - MIPI RFFE Serial Triggering and Decoding
- RTO2024 - RTO-K42 - MIPI D-PHY Serial Triggering and Decoding
- RTO2024 - RTO-K44 - MIPI M-PHY Serial Triggering and Decoding
- RTO2024 - RTO-K50 - Manchester and NRZ Serial Triggering and Decoding
- RTO2024 - RTO-K52 - 8b10b Serial Decoding
- RTO2024 - RTO-K55 - MDIO Serial Triggering and Decoding
- RTO2024 - RTO-K60 - USB 1.0/1.1/2.0/HSIC Serial Triggering and Decoding
- RTO2024 - RTO-K61 - USB 3.1 Gen 1 Serial Triggering and Decoding
- RTO2024 - RTO-K63 - USB Power Delivery Serial Triggering and Decoding
- RTO2024 - RTO-K65 - SpaceWire Serial Triggering and Decoding
- RTO2024 - RTO-K72 - PCI Express 1.1/2.0 Serial Triggering and Decoding
- RTO2024 - RTO-K76 - CXPI Serial Triggering and Decoding
- RTO2024 - RTO-K86 - Energy-Efficient Ethernet Compliance Test (10M/100M/1G-BASE-T)
- RTO2024 - RTO-K87 - 1000BASE-T1 Compliance Test
- RTO2024 - RTO-K92 - eMMC Compliance Test
| Model | RTO2024 |
|---|
The Rohde & Schwarz RTO2024 is a high-end digital oscilloscope offering 2 GHz bandwidth across 4 channels, with 10 Gsample/s sampling and 50 Msample memory per channel, expandable to 2 Gsample. It features a 12.1” capacitive touchscreen, spectrum analysis, 16-bit resolution, and optional protocol tester.
Ideal for EMI debugging and multi-domain testing, the RTO2024 integrates digital channels, waveform generators, and high-speed data interfaces like USB 3.1, LAN, and DVI for external displays.
Testwall can supply the used Rohde & Schwarz RTO2024 Digital Oscilloscope, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Rohde & Schwarz RTO2024 Digital Oscilloscope.
