Rohde & Schwarz SMGL
| Attribute | Value |
|---|---|
| Frequency Range | 100 kHz to 6 GHz |
| Output Power Range | -130 dBm to +18 dBm |
| Frequency Resolution | 0.001 Hz |
| Phase Noise | -134 dBc/Hz at 1 GHz, 20 kHz offset |
| Modulation Types | AM, FM, PM, Pulse Modulation |
| Spectral Purity (Harmonics) | < -30 dBc |
| Output Impedance | 50 Ohm |
| Reference Frequency | 10 MHz internal/external reference |
| Display | 7-inch color touchscreen display |
| Interface Connectivity | USB, LAN (LXI), GPIB |
Rohde & Schwarz SMGL 9KHz-1GHz High Output Level Signal Generator Options:
- SMGL - B1 - Ocxo Reference Oscillator
- SMGL - B2 - Af Synthesiser
- SMGL - B3 - X Output
- SMGL - B4 - Additional Rear I/O
| Model | SMGL |
|---|
The Rohde & Schwarz SMGL Signal Generator operates within a frequency range from 9 kHz to 1 GHz, providing versatile modulation options including AM, FM, and phase modulation as standard. It features exceptional phase noise performance, typically -124 dBc at 1 GHz with a 20 kHz offset, and offers a power range from -140 dBm up to +13 dBm with an outstanding frequency resolution of 1 Hz. Additionally, the unit integrates a broadband power amplifier for enhanced output capabilities.
Ideal for applications such as driving power stages, frequency multipliers, power semiconductor testing, and high-level mixers, the SMGL can be further expanded with option SMGL-B4, enabling independent use of its power amplifier, level control, and attenuator.
Testwall can supply the used Rohde & Schwarz SMGL Signal Generator, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Rohde & Schwarz SMGL Signal Generator.
