Rohde & Schwarz ZV-Z132
0Hz-8GHz, 3.5mm(m) Calibration Kit (1164.1092.02)
DC to 67 GHz Frequency Range
1.0 mm (W connector) Connector Type
50 Ohm Impedance
≤ 1.3 (up to 67 GHz) VSWR (Typical)
≤ 1.5 dB at 67 GHz Insertion Loss (Typical)
| Attribute | Value |
|---|---|
| Frequency Range | DC to 67 GHz |
| Connector Type | 1.0 mm (W connector) |
| Impedance | 50 Ohm |
| VSWR (Typical) | ≤ 1.3 (up to 67 GHz) |
| Insertion Loss (Typical) | ≤ 1.5 dB at 67 GHz |
| Cable Type | Semi-rigid coaxial cable |
| Cable Length | 500 mm (approximately) |
| Maximum Input Power | 0.5 W (average) |
| Operating Temperature Range | 0°C to +55°C |
| Compatible Instruments | Rohde & Schwarz ZVA67, ZVT20, and other VNAs with 1.0 mm ports |
| Model | ZV-Z132 |
|---|
The Rohde & Schwarz ZV-Z132 Calibration Kit (1164.1092.02) operates from 0Hz to 8GHz, featuring precision 3.5mm(m) connectors for accurate vector network analyzer calibration.
Ideal for high-frequency measurements, this kit supports consistent performance and is essential for ensuring reliable test system operation.
Testwall can supply the used Rohde & Schwarz ZV-Z132, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Rohde & Schwarz ZV-Z132.
