Rohde & Schwarz ZVA-Z90
| Attribute | Value |
|---|---|
| Frequency Range | 75 GHz to 90 GHz |
| Frequency Band | W-Band |
| Test Port Connector Type | WR-10 Waveguide |
| Compatible VNA | Rohde & Schwarz ZVA Vector Network Analyzer |
| Conversion Loss (Typical) | 10 dB |
| Output Power (Typical) | -10 dBm |
| Number of Test Ports | 2 |
| Harmonic Order | 6th Harmonic Mixer |
| IF Frequency Range | DC to 200 MHz |
| Operating Temperature Range | 0 °C to 55 °C |
| Model | ZVA-Z90 |
|---|
The Rohde & Schwarz ZVA-Z90 is a millimeter-wave converter extending ZVA or ZNA VNAs to the 60–90 GHz W-band. It offers exceptional S-parameter precision with WR12 waveguide interface, >100 dB dynamic range, and +10 dBm output power. SMA and 2.92 mm connectors enable versatile interfacing.
Ideal for R&D and production, it supports up to 70 dB attenuation, stable performance (<0.2 dB/2°), and differential or multi-port testing, including on-wafer setups.
Testwall can supply the used Rohde & Schwarz ZVA-Z90, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Rohde & Schwarz ZVA-Z90.
