Schaffner NSG 5001
| Attribute | Value |
|---|---|
| Output Voltage Range | Up to 4.4 kV peak |
| ESD Test Standards | IEC 61000-4-2, EN 61000-4-2 |
| Discharge Current | Up to 30 A peak |
| Discharge Modes | Contact discharge and air discharge |
| Polarity | Positive and negative |
| Charge Voltage Accuracy | ±5% |
| Discharge Network | 150 pF / 330 Ω per IEC 61000-4-2 |
| Power Supply | 100–240 V AC, 50/60 Hz |
| Operating Temperature | 15°C to 35°C (59°F to 95°F) |
| Dimensions (W x H x D) | Approximately 300 x 150 x 350 mm |
| Model | NSG 5001 |
|---|
The Schaffner NSG 5001 is an advanced programmable generator system engineered for conducted immunity and transient testing. With precision electronics, it delivers stable and accurate waveform generation, enabling precise simulation of electrical disturbances. Supporting multiple compliance standards, this unit ensures reliable operation in demanding laboratory and industrial environments, while its protective design safeguards connected equipment and itself.
Featuring a user-friendly interface and robust build, the NSG 5001 simplifies setup and operation of complex test sequences. Its stability and accuracy make it ideal for certification, development, and industrial testing applications.
Testwall can supply the used Schaffner NSG 5001, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Schaffner NSG 5001.
