Sorensen
Sorensen DCR32-155T1
32-155A1 DC Power Supply
0 - 32 VDC Output Voltage
0 - 155 A Output Current
5000 W Output Power
208/240 VAC, Single Phase Input Voltage
47 - 63 Hz Input Frequency
| Attribute | Value |
|---|---|
| Output Voltage | 0 - 32 VDC |
| Output Current | 0 - 155 A |
| Output Power | 5000 W |
| Input Voltage | 208/240 VAC, Single Phase |
| Input Frequency | 47 - 63 Hz |
| Line Regulation | 0.01% + 2 mV |
| Load Regulation | 0.01% + 2 mV |
| Ripple and Noise (RMS) | 15 mV RMS |
| Operating Temperature | 0°C to 50°C |
| Cooling Method | Fan Cooled |
Sorensen DCR32-155T1 Options:
- DCR32-155T1 - T1 - STD. U.S. VOLTAGE, 208V, 60HZ
- DCR32-155T1 - T2 - STD. U.S. VOLTAGE, 380V, 50HZ
- DCR32-155T1 - T3 - STD. CONTINENTAL EUROPE VOLTAGE, 415V, 50HZ
- DCR32-155T1 - T5 - STD. BRITISH ISLES VOLTAGE, 480V, 60HZ
- DCR32-155T1 - 1060247-1 - Chassis Slides (Optional)
- DCR32-155T1 - 488 MICRO DAP - Interface to GPIB Bus, Digital Programmer (Optional)
- DCR32-155T1 - M5 - OVP Option: SCR crowbar M5
- DCR32-155T1 - Digital - Digital Metering: Standard
- DCR32-155T1 - Analog - Analog Metering: add M52
| Model | DCR32-155T1 |
|---|
32V, 155A, 4960W
