Sorensen
Sorensen DCS60-18E
60-18A DC Power Supply
0 - 60 VDC Output Voltage
0 - 18 A Output Current
1080 W Output Power
105 - 132 VAC / 210 - 264 VAC, Single Phase Input Voltage
47 - 63 Hz Input Frequency
| Attribute | Value |
|---|---|
| Output Voltage | 0 - 60 VDC |
| Output Current | 0 - 18 A |
| Output Power | 1080 W |
| Input Voltage | 105 - 132 VAC / 210 - 264 VAC, Single Phase |
| Input Frequency | 47 - 63 Hz |
| Line Regulation (Voltage) | 0.01% + 2 mV |
| Load Regulation (Voltage) | 0.01% + 2 mV |
| Ripple and Noise (RMS) | 1 mV RMS typical |
| Programming Interface | Analog (0-5V or 0-10V), with optional GPIB/RS-232 interface |
| Form Factor | Rack Mount, 2U |
Sorensen DCS60-18E Options:
- DCS60-18E - M1 - Factory configured for 115 VAC input (1 kW and 1.2 kW units only)
- DCS60-18E - M9C - Internal IEEE-488/RS 232 Interface Card with voltage and current readback and adjustable OVP (May not be combined with M51A or M85)
- DCS60-18E - M13 - Locking shafts (front panel potentiometers)
- DCS60-18E - M32 - Master/slave paralleling cable configured for two or more units
- DCS60-18E - M51A - Isolated analog programming control of V/I/OVP and isolated V/I monitor and status outputs up to 500V relative to the supply's return line (May not be combined with M9C or M85)
- DCS60-18E - M85 - Multichannel slave interface allows use of a single GPIB address (using 1 master unit with M9C option) to control multiple units via a standard RS485 connector, 3 ft. connector included (May not be combined with M9C or M51A)
| Model | DCS60-18E |
|---|
The Sorensen DCS60-18E 1 kW, Programmable Power Supply utilizes Switch-Mode technology to achieve High Power density in a low profile chassis. Utilizing unique packaging techniques, the DCS60-18E provides continuous Output Power in any volt/Amp combination
