Sorensen
Sorensen DHP 2
0-150 20.0V Power Supply
0 - 600 VDC Output Voltage Range
0 - 16.7 A Output Current Range
10,000 W (10 kW) Output Power
208/240 VAC, 3-Phase Input Voltage
0.02% of full scale Line Regulation (Voltage)
| Attribute | Value |
|---|---|
| Output Voltage Range | 0 - 600 VDC |
| Output Current Range | 0 - 16.7 A |
| Output Power | 10,000 W (10 kW) |
| Input Voltage | 208/240 VAC, 3-Phase |
| Line Regulation (Voltage) | 0.02% of full scale |
| Load Regulation (Voltage) | 0.02% of full scale |
| Ripple and Noise (RMS) | 0.1% of full scale or 50 mV, whichever is greater |
| Programming Interface | Analog, RS-232, GPIB (IEEE-488), and Ethernet (optional) |
| Operating Temperature | 0°C to 50°C |
| Cooling Method | Forced air (fan cooled) |
Sorensen DHP 2 Options:
- DHP - M1 - 360-440 VAC, 47-63 Hz, three phase, 3-wire plus ground, Delta or Wye may be used
- DHP - M2 - 432-528 VAC, 47-63 Hz, three phase, 3-wire plus ground, Delta or Wye may be used
- DHP - M8 - Internal RS-232 remote serial interface
- DHP - M9D - Internal IEEE-488.2 interface
- DHP - M10 - Both IEEE-488.2 and RS-232
- DHP - M11 - RS-232 and isolated analog programming
- DHP - M12 - IEEE-488.2 and isolated analog programming
- DHP - M14 - IEEE-488.2, RS-232 and isolated analog programming
- DHP - M51 - Isolated analog programming Input Voltage Options. This isolation allows users to control power supplies not connected to a common ground. In addition, in systems with high ambient noise or with large ground loop currents the control ground can be isolated from the power ground eliminating problems.
| Model | DHP |
|---|
