Sorensen SFA100-150
| Attribute | Value |
|---|---|
| Output Voltage | 100 VDC |
| Output Current | 150 A |
| Output Power | 15,000 W (15 kW) |
| Input Voltage | 208/240 VAC, 3-Phase |
| Input Frequency | 47–63 Hz |
| Line Regulation | 0.02% of full scale output |
| Load Regulation | 0.05% of full scale output |
| Programming Interface | Analog programming, RS-232/RS-485 optional |
| Cooling Method | Forced air cooling |
| Operating Temperature | 0°C to 50°C |
Sorensen SFA100-150 Options:
- SFA100-150 - AJ - Front panel dust filter - factory installed - 3U unit only
- SFA100-150 - K550212-01 - 3U Rack Slides (for 5kW, 10kW and 15kW models)
- SFA100-150 - 5550568-01 - Front panel dust filter - field installation kit - 3U unit only
- SFA100-150 - K550213-01 - 6U Rack Slides (for 20kW, 25kW and 30kW models)
- SFA100-150 - 9550589-01 - AC input cover - 3U unit only
- SFA100-150 - ETHERNET - LXI compliant 10/100 Base T Ethernet remote control with web server for direct control of power supply via web browser (optional)
- SFA100-150 - ISOLATED ANALOG - Isolated Analog Control, Input to Output Isolation: 500V, compliant with max. terminal float voltage (optional)
| Model | SFA100-150 |
|---|
Sorensen SFA100-150 High Slew Rate DC Source
The Sorensen SFA100-150 High Slew Rate DC Source is a state-of-the-art power supply engineered to deliver precise, high-speed voltage transitions, making it ideal for applications demanding rapid response and accuracy. With a voltage output range of up to 100 volts and a cur output range of up to 150 amps, this power source offers ample power for a diverse range of applications, from electronics testing to industrial automation. Sorensen SFA100-150 High Slew Rate DC Source supprts Fast Load Transient Response to aviod undesired voltage excursions.
The Sorensen SFA100-150 High Slew Rate DC Source builds on the Sorensen SGA series to provide a high-power cur source for laser diode applications. High power laser diodes require well-regulated cur control to avoid catastrophic damage. Under anomalous operating conditions, excessive stored energy in the output circuit of the power supply can result in peak stresses that can permanently damage the device. Providing a constant cur regulation mode only, Sorensen SFA100-150's low stored energy output minimizes damage potential for sensitive devices as well as enabling a cur slew rate of up to 400 A/ms.
Specifications for the Sorensen SFA100-150 High Slew Rate DC Source Include:
| Output Voltage | 0-100 V |
| Output Current | 0-150 A |
| Output Power | 15 kW |
| Efficiency | 87% |
