Sorensen
Sorensen XT120-0.5
Programmable DC Power Supply
0 - 120 VDC Output Voltage
0 - 0.5 A Output Current
60 W Output Power
100/120/220/240 VAC, Single Phase Input Voltage
47 - 63 Hz Input Frequency
| Attribute | Value |
|---|---|
| Output Voltage | 0 - 120 VDC |
| Output Current | 0 - 0.5 A |
| Output Power | 60 W |
| Input Voltage | 100/120/220/240 VAC, Single Phase |
| Input Frequency | 47 - 63 Hz |
| Line Regulation (Voltage) | 0.01% + 2 mV |
| Load Regulation (Voltage) | 0.01% + 2 mV |
| Ripple and Noise (RMS) | 1 mV RMS |
| Operating Temperature | 0°C to 50°C |
| Output Terminals | Binding Posts |
Sorensen XT120-0.5 Options:
- XT120-0.5 - M1 - Power Input Modification: 110V ±10%, 47-63 Hz
- XT120-0.5 - M2 - Power Input Modification: 220V ±10%, 47-63 Hz
- XT120-0.5 - M3 - Power Input Modification: 230V ±10%, 47-63 Hz
- XT120-0.5 - M4 - Power Input Modification: 240V ±10%, 47-63 Hz
- XT120-0.5 - M5A - Analog Programming: Internal interface for full scale remote programming of output voltage and/or current by a 0-10V or 0-10 kΩ external source connected at the rear panel. Includes 0-10V readback, externally adjustable offset and range, front panel adjustable overvoltage protection (OVP), TTL shutdown with selectable logic, master/slave tracking and status signals for programming mode, operating mode, OVP and output fail flag. (May not be combined with M9B)
- XT120-0.5 - M9B - Internal IEEE-488 Interface: Features complete remote programming, including status reporting, settings query and interrupt generation with user designated fault conditions. Both the voltage and current output are precisely programmed directly in volts and amps. (May not be combined with M5A)
- XT120-0.5 - M11 - 10-turn current control potentiometer
- XT120-0.5 - M13 - Locking shafts (front panel potentiometer)
- XT120-0.5 - RM-XHS - Rack Adapter Kit
| Model | XT120-0.5 |
|---|
