Stanford Research PS325
2.5kV - 10mA DC Power Supply
0 to ±2500 V DC Output Voltage Range
±5 mA maximum Output Current
0.05% of full scale Voltage Accuracy
0.1 V Voltage Resolution
Less than 10 mV RMS (10 Hz to 1 MHz) Ripple and Noise
| Attribute | Value |
|---|---|
| Output Voltage Range | 0 to ±2500 V DC |
| Output Current | ±5 mA maximum |
| Voltage Accuracy | 0.05% of full scale |
| Voltage Resolution | 0.1 V |
| Ripple and Noise | Less than 10 mV RMS (10 Hz to 1 MHz) |
| Temperature Coefficient | 50 ppm/°C |
| Output Polarity | Positive, Negative, or Bipolar |
| Interface | RS-232 and GPIB (IEEE-488) |
| Power Requirements | 100–120 VAC or 220–240 VAC, 50/60 Hz, 50 W maximum |
| Operating Temperature Range | 0°C to 40°C |
| Model | PS325 |
|---|
The Stanford Research Systems PS325 is a 2.5 kV - 10.00 mA DC Power Supply
