Stanford Research
Stanford Research SR720
LCR Meter
20 Hz to 20 kHz (LCR measurements) Measurement Range
100 Hz, 120 Hz, 1 kHz, 10 kHz, 100 kHz Test Frequency
0.1% Basic Accuracy
0.001 Ω to 99.999 MΩ Impedance Range
0.01 V to 1 V RMS (adjustable) Test Signal Level
| Attribute | Value |
|---|---|
| Measurement Range | 20 Hz to 20 kHz (LCR measurements) |
| Test Frequency | 100 Hz, 120 Hz, 1 kHz, 10 kHz, 100 kHz |
| Basic Accuracy | 0.1% |
| Impedance Range | 0.001 Ω to 99.999 MΩ |
| Test Signal Level | 0.01 V to 1 V RMS (adjustable) |
| Display | Dual 5-digit LCD display with backlight |
| Measurement Parameters | L, C, R, Z, D, Q, ESR, θ |
| DC Bias | 0 V to 2 V internal DC bias |
| Interface | GPIB (IEEE-488) and RS-232 interfaces |
| Power Requirements | 100–240 VAC, 50/60 Hz, 30 W |
Stanford Research SR720 Options:
- SR720 - Option 01 - GPIB and parts handler interface
| Model | SR720 |
|---|
The SR720 LCR Meter measures resistors, inductors, and capacitors with as little as 0.05 % Error. It is an easy-to-use instrument that is quick to Setup, adjust and calibrate. Five test frequencies and three preSet test levels are available.
