Gigatronics
SyntheSys Research 50212A
VXI Microwave Synthesizer.
Bit Error Rate Tester (BERT) Instrument Type
Up to 12.5 Gbps Data Rate
Differential PECL/CML compatible outputs Pattern Generator Output
PRBS 7, 10, 15, 23, 31 and user-defined patterns Test Patterns
Differential input with adjustable threshold Error Detector Input
| Attribute | Value |
|---|---|
| Instrument Type | Bit Error Rate Tester (BERT) |
| Data Rate | Up to 12.5 Gbps |
| Pattern Generator Output | Differential PECL/CML compatible outputs |
| Test Patterns | PRBS 7, 10, 15, 23, 31 and user-defined patterns |
| Error Detector Input | Differential input with adjustable threshold |
| Output Amplitude | Adjustable from 200 mV to 1200 mV (differential) |
| Clock Reference | Internal and external clock reference supported |
| Interface | GPIB and RS-232 remote control interface |
| Operating Temperature | 0°C to 50°C |
| Power Requirements | 100–240 VAC, 50/60 Hz |
SyntheSys Research 50212A Options:
- 50212A - Option 26 - Built-in 90 dB step attenuator in 10 dB steps (reduces maximum leveled power by 1 dB from 8 to 16 GHz and 2 dB above 16 GHz)
| Model | 50212A |
|---|
The Gigatronics 50212A is a VXI Microwave Synthesizer.
