Gigatronics
SyntheSys Research 50218
VXI Signal Generator.
Bit Error Rate Tester (BERT) Instrument Type
Up to 12.5 Gbps Data Rate
Differential PECL/CML compatible output Pattern Generator Output
Differential input with adjustable threshold Error Detector Input
PRBS 2^7-1, 2^10-1, 2^15-1, 2^23-1, 2^31-1, and user-defined patterns Test Patterns
| Attribute | Value |
|---|---|
| Instrument Type | Bit Error Rate Tester (BERT) |
| Data Rate | Up to 12.5 Gbps |
| Pattern Generator Output | Differential PECL/CML compatible output |
| Error Detector Input | Differential input with adjustable threshold |
| Test Patterns | PRBS 2^7-1, 2^10-1, 2^15-1, 2^23-1, 2^31-1, and user-defined patterns |
| Interface | GPIB and RS-232 remote control interface |
| Output Amplitude | Adjustable output voltage swing |
| Clock Source | Internal and external clock reference supported |
| BER Measurement | Real-time bit error rate measurement and error counting |
| Power Requirements | 100-240 VAC, 50/60 Hz universal power supply |
| Model | 50218 |
|---|
The Gigatronics 50218 is a VXI Signal Generator.
