Gigatronics
SyntheSys Research 80303A
10MHz - 26.5GHz Power Sensor
Bit Error Rate Tester (BERT) Instrument Type
Up to 3.35 Gbps Data Rate
Programmable PRBS and user-defined patterns Pattern Generator Output
100 mV to 1 V (differential) Error Detector Input Sensitivity
Adjustable, up to 1.6 V peak-to-peak Output Voltage Swing
| Attribute | Value |
|---|---|
| Instrument Type | Bit Error Rate Tester (BERT) |
| Data Rate | Up to 3.35 Gbps |
| Pattern Generator Output | Programmable PRBS and user-defined patterns |
| Error Detector Input Sensitivity | 100 mV to 1 V (differential) |
| Output Voltage Swing | Adjustable, up to 1.6 V peak-to-peak |
| Interface | GPIB and RS-232 |
| Clock Source | Internal and external clock reference supported |
| PRBS Patterns Supported | 2^7-1, 2^10-1, 2^15-1, 2^23-1, 2^31-1 |
| Operating Temperature | 0°C to 50°C |
| Power Requirements | 100–240 VAC, 50/60 Hz |
| Model | 80303A |
|---|
10 MHz to 26.5 GHz Power Sensor
