Gigatronics
SyntheSys Research 80340A
45MHz - 18GHz 50Ohm Peak Power Sensor
Bit Error Rate Tester (BERT) Instrument Type
Up to 40 Gbps Data Rate
Differential and single-ended outputs Pattern Generator Output
100 MHz to 40 GHz Clock Frequency Range
Adjustable, up to 2 Vpp Output Amplitude
| Attribute | Value |
|---|---|
| Instrument Type | Bit Error Rate Tester (BERT) |
| Data Rate | Up to 40 Gbps |
| Pattern Generator Output | Differential and single-ended outputs |
| Clock Frequency Range | 100 MHz to 40 GHz |
| Output Amplitude | Adjustable, up to 2 Vpp |
| PRBS Patterns Supported | PRBS 7, 10, 15, 23, 31 |
| Interface | GPIB and USB remote control interfaces |
| Error Detection | Real-time bit error rate measurement and analysis |
| Input Sensitivity | High-sensitivity error detector input for signal integrity testing |
| Application | High-speed serial data link testing, optical and electrical signal characterization |
SyntheSys Research 80340A Options:
- 80340A - 20954-001 - 1.5 meter cable (5 feet)
- 80340A - 20954-002 - 3.0 meter cable (10 feet)
- 80340A - 20954-003 - 7.6 meter cable (25 feet)
- 80340A - 20954-004 - 15.2 meter cable (50 feet)
| Model | 80340A |
|---|
45 MHz to 18 GHz, -20 to +20 dBm, Peak -30 to +20 dBm, CW, Type N(m), 50 Ohm, Peak Power Sensor
