Tektronix DPO2AUTO
| Attribute | Value |
|---|---|
| Compatible Oscilloscope Series | Tektronix DPO2000 and MSO2000 Series |
| Application Type | Automotive Serial Bus Triggering and Analysis Module |
| Supported Protocols | CAN, LIN |
| CAN Bus Signaling Rate | Up to 1 Mb/s |
| LIN Bus Signaling Rate | Up to 20 kb/s |
| Trigger Capabilities | Trigger on CAN and LIN frames, error conditions, and specific data fields |
| Decode Capabilities | Automatic packet decode with color-coded bus overlay display |
| Search Functionality | Search across acquisition for specific bus events and conditions |
| Installation Method | Software license key activated directly on the oscilloscope |
| License Type | Permanent application module license |
Tektronix DPO2AUTO Options:
- DPO2AUTO - DPO2EMBD - I²C, SPI Serial Triggering and Analysis Module for MSO/DPO2000B Series
- DPO2AUTO - DPO2COMP - RS-232/422/485/UART Serial Triggering and Analysis Module for MSO/DPO2000B Series
- DPO2AUTO - DPO2AUTO - CAN, LIN Serial Triggering and Analysis Module for MSO/DPO2000B Series
| Model | DPO2AUTO |
|---|
The Tektronix DPO2AUTO for DPO2000 Series oscilloscopes enables advanced automotive serial trigger and decode options for CAN, LIN, and other protocols. It supports 100 MHz and 200 MHz bandwidth models with up to 1 GS/s sample rates and a full 1 M record length on all channels. The system includes FilterVu™ low-pass filtering, Wave Inspector® tools, and a 7-inch TFT-LCD display for efficient signal analysis.
This module is essential for automotive electronics, embedded design, and power measurements, with easy connectivity through USB and TekVPI® probe support.
Testwall can supply the used Tektronix DPO2AUTO, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix DPO2AUTO.
