Tektronix DPO4034
| Attribute | Value |
|---|---|
| Number of Channels | 4 |
| Bandwidth | 350 MHz |
| Sample Rate | 2.5 GS/s |
| Record Length | 10 M points |
| Vertical Resolution | 8 bits |
| Rise Time | 1 ns |
| Input Impedance | 1 MΩ or 50 Ω |
| Display | 10.4 inch (264 mm) color TFT LCD |
| Waveform Capture Rate | Up to 50,000 waveforms per second |
| Connectivity | USB, Ethernet (LAN), CompactFlash |
Tektronix DPO4034 Options:
Options available for the Tektronix DPO/MSO4000 Series. Installed options vary from unit to unit – ask us for the exact configuration of the instrument you are interested in.
- DPO4034 - DPO4AERO - Aerospace serial triggering and analysis (MIL-STD-1553)
- DPO4034 - DPO4AUDIO - Audio serial triggering and analysis (I2S, LJ, RJ, TDM)
- DPO4034 - DPO4AUTO - Automotive serial triggering and analysis (CAN, LIN)
- DPO4034 - DPO4AUTOMAX - Extended automotive serial triggering and analysis (CAN, LIN, FlexRay)
- DPO4034 - DPO4COMP - Computer serial triggering and analysis (RS-232/422/485, UART)
- DPO4034 - DPO4EMBD - Embedded serial triggering and analysis (I2C, SPI)
- DPO4034 - DPO4ENET - Ethernet serial triggering and analysis (10BASE-T, 100BASE-TX)
- DPO4034 - DPO4USB - USB 2.0 serial triggering and analysis
- DPO4034 - DPO4LMT - Limit and mask testing
- DPO4034 - DPO4PWR - Power measurement and analysis
- DPO4034 - DPO4VID - Extended video triggering
- DPO4034 - DPO4BND - Application bundle (all DPO4 serial, power, limit/mask and video modules)
The Tektronix DPO4034 Digital Phosphor Oscilloscope offers 350 MHz bandwidth, 2.5 GS/s sample rate across 4 analog channels, and a 10 Mpoint record length per channel. With over 50,000 wfm/s waveform capture rate and 1 ns rise time, it ensures high-resolution signal analysis. Features like TekVPI® probe interface, Wave Inspector® controls, and a 10.4-inch XGA display enhance usability.
Ideal for advanced debugging, the DPO4034 supports USB, Ethernet, and video out connectivity, plus automated serial triggering and analysis for protocols such as I²C, SPI, USB, CAN, LIN and more.
Testwall can supply the used Tektronix DPO4034, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix DPO4034.
