Tektronix DPO5104
| Attribute | Value |
|---|---|
| Bandwidth | 1 GHz |
| Number of Channels | 4 |
| Sample Rate | 5 GS/s |
| Record Length | 25 M points standard (250 M points optional) |
| Vertical Resolution | 8-bit (11-bit with Hi-Res mode) |
| Rise Time | 350 ps |
| Input Impedance | 1 MΩ or 50 Ω |
| Display | 10.4-inch (264 mm) color LCD touchscreen |
| Waveform Capture Rate | Up to 340,000 waveforms per second |
| Connectivity | USB, LAN (LXI), GPIB (optional), CompactFlash |
Tektronix DPO5104 Options:
Options available for the Tektronix DPO/MSO5000 Series. Installed options vary from unit to unit – ask us for the exact configuration of the instrument you are interested in.
- DPO5104 - 5RL - Record length extension to 50 M points per channel
- DPO5104 - 10RL - Record length extension to 125 M points per channel
- DPO5104 - SR-AERO - Aerospace serial triggering and analysis (MIL-STD-1553)
- DPO5104 - SR-DPHY - MIPI D-PHY (DSI-1, CSI-2) serial analysis
- DPO5104 - MTM - Mask testing (telecom, data and video standards)
- DPO5104 - BRR - BroadR-Reach automotive Ethernet compliance
- DPO5104 - HSIC - USB HSIC decode and electrical validation
- DPO5104 - MOST - MOST50 / MOST150 electrical compliance and debug
- DPO5104 - SR-AUTO - Automotive serial triggering and analysis (CAN, LIN, FlexRay)
- DPO5104 - SR-COMP - Computer serial triggering and analysis (RS-232/422/485, UART)
- DPO5104 - SR-EMBD - Embedded serial triggering and analysis (I2C, SPI)
- DPO5104 - SR-ENET - Ethernet serial analysis (10BASE-T, 100BASE-TX)
- DPO5104 - SR-USB - USB 2.0 serial triggering and analysis
- DPO5104 - DJA - DPOJET advanced jitter and eye diagram analysis
- DPO5104 - DDRA - DDR memory bus analysis (requires DJA)
- DPO5104 - PWR - Power measurement and analysis (DPOPWR)
- DPO5104 - ET3 - Ethernet compliance testing (10/100/1000BASE-T)
The Tektronix DPO5104 is a 4-channel benchtop oscilloscope from the MSO5000/DPO5000 Series offering a 1000 MHz bandwidth and powerful signal visualization. It operates on a Windows OS, making it highly accessible for technical users.
Ideal for high-speed design and debugging, this scope provides real-time signal capture and precise measurement with its high bandwidth and multi-channel capability.
Testwall can supply the used Tektronix DPO5104, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix DPO5104.
