Tektronix DPO7OE2
| Attribute | Value |
|---|---|
| Optical Input Wavelength Range | 750 nm to 1650 nm |
| Electrical Bandwidth | 12.5 GHz |
| Rise Time | 28 ps |
| Optical Input Connector | FC/PC |
| Compatible Oscilloscope Series | DPO7000, DSA7000, MSO70000 Series |
| Conversion Gain | 700 V/W typical |
| Maximum Input Power | +10 dBm average, +30 dBm peak |
| Interface | SMA electrical output to oscilloscope front-end input |
| Operating Temperature | 0°C to +50°C |
| Power Supply | Powered directly through the oscilloscope optical module interface |
Tektronix DPO7OE2 Options:
- DPO7OE2 - FC/APC - FC/APC optical input connector (typically used in research applications)
- DPO7OE2 - FC/PC - FC/PC optical input connector (typically used in networking/data center network applications)
- DPO7OE2 - C3 - Calibration Service 3 Years
- DPO7OE2 - C5 - Calibration Service 5 Years
- DPO7OE2 - D3 - Calibration Data Report 3 Years (with Opt. C3)
- DPO7OE2 - D5 - Calibration Data Report 5 Years (with Opt. C5)
- DPO7OE2 - G3 - Complete Care 3 Years (includes loaner, scheduled calibration, and more)
- DPO7OE2 - G5 - Complete Care 5 Years (includes loaner, scheduled calibration, and more)
- DPO7OE2 - R3 - Repair Service 3 Years (including warranty)
- DPO7OE2 - R5 - Repair Service 5 Years (including warranty)
| Model | DPO7OE2 |
|---|
The Tektronix DPO7OE2 optical probe delivers up to 59 GHz electrical bandwidth for deep signal analysis. It supports optical reference receiver (ORR) filtering for 25–53 GBd standards and is compatible with ATI and TekConnect channels. Broad wavelength coverage, low noise, and high sensitivity ensure excellent SNR in high-speed signal environments.
Perfect for analyzing PAM4/PAM2 signals, validating data center networking equipment, and optical interface debugging. Offers FC/PC or FC/APC connectors and supports Bessel-Thomson ORR filters for accurate, standard-compliant measurements.
Testwall can supply the used Tektronix DPO7OE2, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix DPO7OE2.
