Tektronix
Tektronix PPG3004
4 Channel Programmable Pattern Generator 30 Gb/s
4 Number of Channels
3.35 Gb/s per channel Maximum Data Rate
0.4 V to 2.0 V (differential peak-to-peak) Voltage Output Range
≤ 120 ps (typical, 20% to 80%) Rise/Fall Time
Up to 256 Mb per channel Pattern Memory Depth
| Attribute | Value |
|---|---|
| Number of Channels | 4 |
| Maximum Data Rate | 3.35 Gb/s per channel |
| Voltage Output Range | 0.4 V to 2.0 V (differential peak-to-peak) |
| Rise/Fall Time | ≤ 120 ps (typical, 20% to 80%) |
| Pattern Memory Depth | Up to 256 Mb per channel |
| Output Impedance | 50 Ω |
| Clock Frequency Range | 100 MHz to 3.35 GHz |
| Jitter (RMS) | < 1 ps RMS (typical) |
| Interface/Connectivity | USB, LAN (LXI compliant), GPIB (optional) |
| Form Factor | Benchtop, 2U half-rack |
Tektronix PPG3004 Options:
- PPG3004 - HFJIT - High frequency jitter option for PPG3004
- PPG3004 - A0 - North America power plug (115 V, 60 Hz)
- PPG3004 - A1 - Universal Euro power plug (220 V, 50 Hz)
- PPG3004 - A2 - United Kingdom power plug (240 V, 50 Hz)
- PPG3004 - A6 - Japan power plug (100 V, 50/60 Hz)
- PPG3004 - A10 - China power plug (50 Hz)
- PPG3004 - A11 - India power plug (50 Hz)
- PPG3004 - A99 - No power cord
| Model | PPG3004 |
|---|
The Tektronix PPG3004 PatternPro® features 1–4 channels of 16 to 32 Gb/s outputs, with adjustable amplitude (250 mV–2.0 V), jitter insertion (BUJ, SJ, RJ, PJ), PRBS/user patterns, and built-in clock source for precision high-speed testing.
Engineered for 100G Ethernet, PAM4, and DP-QPSK testing, it provides touch screen GUI, USB control, phase delay, and integrates with PED series for complete multi-channel BER solutions.
Testwall can supply the used Tektronix PPG3004, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix PPG3004.
