Tektronix
Tektronix PS2521G
130 Watt DC Power Supply
3 Number of Outputs
0–20 V (two adjustable outputs), 5 V fixed output Output Voltage Range
0–500 mA (adjustable outputs), 1 A (5 V fixed output) Output Current Range
42.5 W maximum Total Power Output
≤ 5 mV (CV mode), ≤ 2 mA (CC mode) Regulation (Load)
| Attribute | Value |
|---|---|
| Number of Outputs | 3 |
| Output Voltage Range | 0–20 V (two adjustable outputs), 5 V fixed output |
| Output Current Range | 0–500 mA (adjustable outputs), 1 A (5 V fixed output) |
| Total Power Output | 42.5 W maximum |
| Regulation (Load) | ≤ 5 mV (CV mode), ≤ 2 mA (CC mode) |
| Regulation (Line) | ≤ 2 mV (CV mode), ≤ 1 mA (CC mode) |
| Ripple and Noise | ≤ 1 mV RMS (CV mode), ≤ 1 mA RMS (CC mode) |
| Display | 3.5-digit LED meters for voltage and current on each adjustable output |
| Operating Temperature | 0°C to 40°C |
| Input Voltage | 115 V AC / 230 V AC, 50/60 Hz |
Tektronix PS2521G Options:
- PS2521G - 159-0023-00 - Fuse, 3AG, 2A, 250V, SB (198-250 V operation)
- PS2521G - 161-0104-06 - Power Cord, Europe 230V
- PS2521G - 161-0104-07 - Power Cord, United Kingdom 230V
- PS2521G - 161-0104-05 - Power Cord, Australia 230V
- PS2521G - 161-0104-08 - Power Cord, North America 230V
- PS2521G - 161-0167-00 - Power Cord, Switzerland 230V
| Model | PS2521G |
|---|
The Tektronix PS2521G is a triple output power supply featuring one 0–6 V, 0–5 A channel and two 0–20 V, 0–2.5 A channels, SCPI-compatible GPIB control, and independent, series, or parallel operation modes.
With 100 programmable memory settings, dual 4-digit LED display, and wide application range from design to field repair, it ensures precise and flexible power delivery in various test environments.
Testwall can supply the used Tektronix PS2521G, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix PS2521G.
