Tektronix PWS2326
| Attribute | Value |
|---|---|
| Output Voltage Range | 0 to 32 V |
| Output Current Range | 0 to 6 A |
| Number of Output Channels | 1 |
| Voltage Regulation (Line) | ≤ 0.01% + 2 mV |
| Current Regulation (Line) | ≤ 0.01% + 1 mA |
| Ripple and Noise (Voltage, RMS) | ≤ 1 mVrms |
| Ripple and Noise (Current, RMS) | ≤ 3 mArms |
| Display Type | Dual 4-digit LED display (voltage and current) |
| AC Input Voltage | 100 V to 240 V AC, 50/60 Hz |
| Operating Temperature Range | 0°C to 40°C |
Tektronix PWS2326 Options:
- PWS2326 - A0 - Power Plug: North America
- PWS2326 - A1 - Power Plug: Universal Euro
- PWS2326 - A2 - Power Plug: United Kingdom
- PWS2326 - A3 - Power Plug: Australia
- PWS2326 - A5 - Power Plug: Switzerland
- PWS2326 - A10 - Power Plug: China
- PWS2326 - A11 - Power Plug: India
- PWS2326 - A12 - Power Plug: Brazil
- PWS2326 - L0 - Language: English
- PWS2326 - L1 - Language: French
- PWS2326 - L2 - Language: Italian
- PWS2326 - L3 - Language: German
- PWS2326 - L4 - Language: Spanish
- PWS2326 - L6 - Language: Portuguese
- PWS2326 - L7 - Language: Simplified Chinese
- PWS2326 - L8 - Language: Traditional Chinese
- PWS2326 - L9 - Language: Korean
- PWS2326 - L10 - Language: Russian
- PWS2326 - C3 - Calibration Service 3 Years
- PWS2326 - C5 - Calibration Service 5 Years
- PWS2326 - CA1 - Provides a single calibration event, or coverage for the designated calibration interval, whichever comes first
- PWS2326 - D1 - Calibration Data Report
- PWS2326 - D3 - Calibration Data Report 3 Years (with Option C3)
- PWS2326 - D5 - Calibration Data Report 5 Years (with Option C5)
- PWS2326 - R5 - Repair Service 5 Years
- PWS2326 - SILV100 - Standard Warranty Extended to 5 Years
| Model | PWS2326 |
|---|
Tektronix PWS2326 DC Power Supply
The Tektronix PWS2326 Power Supply is designed with the ease-of-use and familiar operations. With wide cur and voltage ranges, plus 10 mA and 10 mV resolution, the PWS2326 Power Supply satisfies a wide variety of applications. With less than 3 mVp-p Ripple and Noise, linear regulation and 0.05% voltage accuracy, it provides a clean, accurate power you need at an affordable price.
The direct-entry numeric keypad makes it easy to enter precise voltage and cur values. Up/Down controls, with variable step-size, allow you vary output parameters in an increment size you choose. You can also specify a maximum output voltage, which will prevent accidental voltage settings above the specified maximum. A bright vacuum fluorescent display with large digits provides excellent readability at a distance, at an angle, or under dim lighting conditions. You can save your instrument settings in one of the 20 internal memory locations by simply pressing the Save button. Each time you want to recall that setting, just push the Recall button and choose the desired pre-set.
Specifications for the Tektronix PWS2326 DC Power Supply Include:
| Output Voltage | 0 to 32 V |
| Output Current | 0 to 6 A |
| Load Regulation Voltage | ‰¤0.04% + 6 mV |
| Power Consumption | 700 VA |
