Tektronix TBS1152B-EDU
| Attribute | Value |
|---|---|
| Bandwidth | 150 MHz |
| Number of Channels | 2 |
| Sample Rate | 1 GS/s |
| Record Length | 2,500 points |
| Vertical Resolution | 8-bit |
| Vertical Sensitivity | 2 mV/div to 5 V/div |
| Time Base Range | 5 ns/div to 50 s/div |
| Display | 7-inch WVGA (800 x 480) TFT Color LCD |
| Connectivity | USB 2.0 Host and Device ports |
| Included Courseware | OpenChoice Laboratory Courseware with 28 lab exercises for student and instructor use |
Tektronix TBS1152B-EDU Options:
- TBS1152B-EDU - Opt. L1 - French overlay
- TBS1152B-EDU - Opt. L2 - Italian overlay
- TBS1152B-EDU - Opt. L3 - German overlay
- TBS1152B-EDU - Opt. L4 - Spanish overlay
- TBS1152B-EDU - Opt. L5 - Japanese overlay
- TBS1152B-EDU - Opt. L6 - Portuguese overlay
- TBS1152B-EDU - Opt. L7 - Simplified Chinese overlay
- TBS1152B-EDU - Opt. L8 - Traditional Chinese overlay
- TBS1152B-EDU - Opt. L9 - Korean overlay
- TBS1152B-EDU - Opt. L10 - Russian overlay
- TBS1152B-EDU - Opt. A0 - North America power plug (115 V, 60 Hz)
- TBS1152B-EDU - Opt. A1 - Universal Euro power plug (220 V, 50 Hz)
- TBS1152B-EDU - Opt. A2 - United Kingdom power plug (240 V, 50 Hz)
- TBS1152B-EDU - Opt. A3 - Australia power plug (240 V, 50 Hz)
- TBS1152B-EDU - Opt. A4 - North America power plug (240 V, 50 Hz)
- TBS1152B-EDU - Opt. A5 - Switzerland power plug (220 V, 50 Hz)
- TBS1152B-EDU - Opt. A6 - Japan power plug (100 V, 50/60 Hz)
- TBS1152B-EDU - Opt. A10 - China power plug (50 Hz)
- TBS1152B-EDU - Opt. A11 - India power plug (50 Hz)
- TBS1152B-EDU - Opt. A12 - Brazil power plug (60 Hz)
- TBS1152B-EDU - Opt. A99 - No power cord
- TBS1152B-EDU - Opt. D1 - Calibration Data Report
- TBS1152B-EDU - TBS1XX2B-EDU P2220 - Replaces standard probes with P2220 probes (200 MHz passive voltage probes with 1x/10x attenuation)
| Model | TBS1152B-EDU |
|---|
The Tektronix TBS1152B-EDU Digital Storage Oscilloscope delivers 150 MHz bandwidth, 2 channels, and a 2 GS/s sample rate. With 2.5k point record length, USB connectivity, and 34 automated measurements, it includes advanced features like FFT, trend plot, waveform limit testing, dual frequency counter, and a 7" WVGA color display.
Designed for performance and usability, it includes automated data logging, zoom, context help, multilingual UI, and a compact footprint, ideal for bench or educational use.
Testwall can supply the used Tektronix TBS1152B-EDU, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix TBS1152B-EDU.
