Tektronix TCA-SMA
| Attribute | Value |
|---|---|
| Connector Type | SMA to BNC adapter |
| Bandwidth | DC to 3 GHz |
| Input Connector | SMA (female) |
| Output Connector | TekConnect |
| Impedance | 50 Ohm |
| Compatible Instruments | Tektronix TDS/CSA/DSA series oscilloscopes with TekConnect interface |
| Attenuation | 1x (no attenuation) |
| Maximum Input Voltage | 5 V RMS |
| Operating Temperature | 0°C to +50°C |
| Storage Temperature | -20°C to +60°C |
Tektronix TCA-SMA Options:
- TCA-SMA - P6150 - 9 GHz, 1X/10X, 50Ω divider probe (use with TCA-SMA)
- TCA-SMA - P6158 - 3 GHz, 20X, 50Ω divider probe (use with TCA-BNC)
- TCA-SMA - P6205 - 750 MHz, 10X, <2 pF / 10 MΩ (use with TCA-BNC)
- TCA-SMA - P6243 - 1 GHz, 10X, <1 pF / 1 MΩ (use with TCA-BNC)
- TCA-SMA - P6245 - 1.5 GHz, 10X, <1 pF / 1 MΩ (use with TCA-BNC)
- TCA-SMA - P6249 - 4 GHz, 5X, <1 pF / 20 kΩ (use with TCA-BNC)
- TCA-SMA - P6241 - 4 GHz, 10X, <0.5 pF / 40 kΩ (use with TCA-BNC)
- TCA-SMA - P6247 - 1 GHz, 1X/10X, <1 pF / 200 kΩ differential (use with TCA-BNC)
- TCA-SMA - P6248 - 1.5 GHz, 1X/10X, <1 pF / 200 kΩ differential (use with TCA-BNC)
- TCA-SMA - P6330 - 3.5 GHz, 1X/10X, <1 pF / 200 kΩ differential (use with TCA-BNC)
- TCA-SMA - AMT75 - 75Ω to 50Ω video adapter (use with TCA-BNC)
- TCA-SMA - AFTDS - Differential communications adapter (use with TCA-BNC)
- TCA-SMA - TCP202 - AC/DC, 20 A, TekProbe™ interconnect current probe (use with TCA-BNC)
- TCA-SMA - CT-1 - 1 GHz, AC current transformer (use with TCA-BNC)
- TCA-SMA - CT-2 - 200 MHz, AC current transformer (use with TCA-BNC)
- TCA-SMA - CT-6 - 2 GHz, AC current transformer (use with TCA-BNC)
- TCA-SMA - 012-0057-01 - 50Ω BNC-to-BNC coaxial cable (use with TCA-BNC)
- TCA-SMA - 012-0482-00 - 50Ω BNC-to-BNC coaxial cable, precision 1%, male-to-male (use with TCA-BNC)
- TCA-SMA - 011-0049-02 - 50Ω feed-through termination (use with TCA-BNC)
| Model | TCA-SMA |
|---|
The Tektronix TCA-SMA Adapter enables direct TekConnect-to-SMA connections with 50 Ω input and bandwidth up to ≥18 GHz (instrument dependent). It ensures minimal signal distortion and supports high-speed testing without added conversion loss, ideal for precision measurement environments.
Designed for signal integrity, jitter, and timing analysis in digital circuits, power systems, video design, and RF applications across consumer, industrial, and communication sectors.
Testwall can supply the used Tektronix TCA-SMA, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix TCA-SMA.
