Tektronix TDS5104
| Attribute | Value |
|---|---|
| Bandwidth | 1 GHz |
| Number of Channels | 4 |
| Sample Rate | 5 GS/s (on all channels simultaneously) |
| Record Length | Up to 16,000,000 points |
| Vertical Resolution | 8-bit (up to 11-bit with Hi Res mode) |
| Rise Time | 350 ps |
| Input Impedance | 1 MΩ or 50 Ω |
| Display | 10.4-inch color LCD touchscreen |
| Operating System | Windows XP Embedded |
| Connectivity | USB, GPIB, Ethernet (LAN), Compact Flash |
Tektronix TDS5104 Options:
- TDS5104 - Opt. 18 - Touch-screen interface
- TDS5104 - Opt. 3M - Increase record length to 16M samples max (1ch.)
- TDS5104 - Opt. 1P - Built-in thermal printer
- TDS5104 - Opt. FHD - Front panel removable hard drive (replaces FDD and internal HDD)
- TDS5104 - Opt. 1K - Oscilloscope cart
- TDS5104 - Opt. 1R - Rackmount kit
- TDS5104 - Opt. SM - Communication mask testing
- TDS5104 - Opt. CP2 - TDSCPM2 - ANSI/ITU telecom pulse compliance testing software (requires Opt. SM)
- TDS5104 - Opt. DVD - TDSDVD - Optical storage analysis software
- TDS5104 - Opt. ET3 - TDSET3 - Ethernet compliance test software
- TDS5104 - Opt. J2 - TDSDDM2 - Disk drive measurements software
- TDS5104 - Opt. J3E - TDSJIT3E - Jitter and timing analysis software essentials
- TDS5104 - Opt. JT3 - TDSJIT3 - Jitter and timing analysis software with Rj/Dj and BER
- TDS5104 - Opt. PW3 - TDSPWR3 - Power measurements software
- TDS5104 - Opt. USB - USB 2.0 Compliance test software only
- TDS5104 - Opt. A0 - Power plug: North America
- TDS5104 - Opt. A1 - Power plug: Universal Euro
- TDS5104 - Opt. A2 - Power plug: United Kingdom
- TDS5104 - Opt. A3 - Power plug: Australia
- TDS5104 - Opt. A4 - Power plug: 240 V North America
- TDS5104 - Opt. A5 - Power plug: Switzerland
- TDS5104 - Opt. A6 - Power plug: Japan
- TDS5104 - Opt. A10 - Power plug: China
- TDS5104 - Opt. A99 - No power cord or AC adapter
- TDS5104 - Opt. L0 - English manual
- TDS5104 - Opt. L1 - French manual
- TDS5104 - Opt. L3 - German manual
- TDS5104 - Opt. L5 - Japanese manual
- TDS5104 - Opt. L7 - Simple Chinese manual
- TDS5104 - Opt. L8 - Traditional Chinese manual
- TDS5104 - Opt. L9 - Korean manual
- TDS5104 - Opt. L10 - Russian manual
- TDS5104 - Opt. C3 - Calibration Service 3 Years
- TDS5104 - Opt. C5 - Calibration Service 5 Years
- TDS5104 - Opt. D1 - Calibration Data Report
- TDS5104 - Opt. D3 - Calibration Data Report 3 Years (with Option C3)
- TDS5104 - Opt. D5 - Calibration Data Report 5 Years (with Option C5)
- TDS5104 - Opt. R3 - Repair Service 3 Years (including warranty)
- TDS5104 - Opt. R5 - Repair Service 5 Years (including warranty)
| Model | TDS5104 |
|---|
The Tektronix TDS5104 oscilloscope offers 4 independent 1 GHz channels with a 5 GS/s real-time sample rate and 400K record length. It supports up to 100,000 wfms/s waveform capture rate, and includes advanced triggering options like edge, glitch, and transition triggers. Its built-in waveform measurement capabilities include amplitude, time, and combination metrics.
Perfect for signal diagnostics, it provides detailed insights such as rise/fall time, DC/AC components, and noise variation over time, with waveform math processing including FFT and multiple window functions.
Testwall can supply the used Tektronix TDS5104, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix TDS5104
