Tektronix TM506
| Attribute | Value |
|---|---|
| Number of Plug-In Slots | 6 |
| Power Supply Output | ±15V, +5V, -12.6V, +55V, -55V |
| Maximum Power Dissipation | 150W total |
| AC Input Voltage | 90–250V AC (auto-ranging) |
| AC Input Frequency | 48–440 Hz |
| Power Consumption | 250VA maximum |
| Compatible Plug-In Modules | Tektronix TM500 and TM5000 series plug-in modules |
| Cooling | Forced air cooling with internal fan |
| Operating Temperature | 0°C to +50°C |
| Form Factor | Benchtop mainframe chassis |
Tektronix TM506 Options:
- TM506 - 02 - Rear Interface
| Model | TM506 |
|---|
The Tektronix TM506 is a versatile power module mainframe engineered for the TM500-Series of modular instruments. It supports up to six single-width plug-in modules or various slot combinations, making it adaptable for a wide range of test and measurement setups. Compatible plug-ins include oscilloscopes, DMMs, function generators, counters, calibration tools, and more.
This compact mainframe allows users to consolidate multiple instruments into one unit, saving space and enhancing laboratory efficiency. Plug-ins are sold separately.
Testwall can supply the used Tektronix TM506, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix TM506.
