Teledyne LeCroy
Teledyne LeCroy WAVEPRO7200A
4 Ch 2 GHz Digital Oscilloscope
2 GHz Bandwidth
10 GS/s (on 2 channels), 5 GS/s (on 4 channels) Sample Rate
4 Number of Channels
Up to 48 Mpts/Ch (with optional memory upgrade) Memory Depth
8 bits Vertical Resolution
| Attribute | Value |
|---|---|
| Bandwidth | 2 GHz |
| Sample Rate | 10 GS/s (on 2 channels), 5 GS/s (on 4 channels) |
| Number of Channels | 4 |
| Memory Depth | Up to 48 Mpts/Ch (with optional memory upgrade) |
| Vertical Resolution | 8 bits |
| Vertical Sensitivity | 1 mV/div to 1 V/div |
| Timebase Range | 20 ps/div to 1000 s/div |
| Input Impedance | 50 Ω or 1 MΩ |
| Display | 10.4-inch color LCD touchscreen |
| Connectivity | USB, Ethernet (LAN), GPIB (optional) |
Teledyne LeCroy WAVEPRO7200A Options:
- WAVEPRO7200A - WP7-VL - Memory Option: 32 Mpts/2 Ch, 16 Mpts/Ch
- WAVEPRO7200A - WP7-XL - Memory Option: 48 Mpts/2 Ch, 24 Mpts/Ch
- WAVEPRO7200A - XMATH - Advanced Math Software Package
- WAVEPRO7200A - XDEV - Advanced Customization Software Package
- WAVEPRO7200A - XWEB - Processing Web Editor Software Package for Functions and Parameters
- WAVEPRO7200A - JTA2 - Jitter and Timing Analysis Software Package
- WAVEPRO7200A - XMAP - Master Analysis Software Package (Includes JTA2, XMATH, and XDEV)
- WAVEPRO7200A - DFP2 - Digital Filter Software Package
- WAVEPRO7200A - SDM - Serial Data Mask Software Package
- WAVEPRO7200A - ENET - Ethernet Test Software Package
- WAVEPRO7200A - USB2 - USB 2.0 Compliance Test Software Package
- WAVEPRO7200A - DDM2 - Disk Drive Measurement Software Package
- WAVEPRO7200A - AORM - Advanced Optical Recording Measurement Software Package
- WAVEPRO7200A - PMA2 - PowerMeasure Analysis Software Package
- WAVEPRO7200A - WP7-EMC - EMC Pulse Parameter Software Package
- WAVEPRO7200A - GPIB-1 - IEEE-488 GPIB Control Interface
- WAVEPRO7200A - WM-GP02 - Internal Graphics Printer
- WAVEPRO7200A - WM-RHD - Removable Hard Drive Package (includes USB, CD-ROM, removable hard drive and spare hard drive)
- WAVEPRO7200A - WM-RHD-02 - Additional Removable Hard Drive
- WAVEPRO7200A - WM-CDRW - CD-ROM Read/Write Upgrade
- WAVEPRO7200A - DMD-1 - Dual Monitor Display
- WAVEPRO7200A - MS-32-DSA - 32 Digital Channel Oscilloscope Mixed Signal Option
- WAVEPRO7200A - CANbus TDM - CANbus TDM Trigger, Decode and Measure/Graph Testing Option
- WAVEPRO7200A - CANbus TD - CANbus TD Trigger and Decode Testing Option
| Model | WAVEPRO7200A |
|---|
The Teledyne LeCroy WavePro 7200A oscilloscope delivers 2 GHz bandwidth with 10 GS/s per channel (20 GS/s interleaved) plus XXL configurations up to 100 Mpts per channel, and X-Stream II boosts data transfer to ~325 MB/s via LSIB on a 15.3″ high-resolution widescreen touch display.
Featuring advanced jitter/timing tools and scripting support (XDEV, XMAP), it's tailored for sophisticated debugging, design verification, and demanding signal-analysis workloads.
Testwall can supply the used WavePro 7200A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the WavePro 7200A.
