TTI Thurlby
TTI Thurlby Thandar Instruments 9507B
10 Hz to 2 MHz Frequency Range
Sine, Square, Triangle, Ramp, Pulse Output Waveforms
Up to 20 V peak-to-peak (into open circuit) Output Amplitude
50 Ohms Output Impedance
4 digits Frequency Resolution
| Attribute | Value |
|---|---|
| Frequency Range | 10 Hz to 2 MHz |
| Output Waveforms | Sine, Square, Triangle, Ramp, Pulse |
| Output Amplitude | Up to 20 V peak-to-peak (into open circuit) |
| Output Impedance | 50 Ohms |
| Frequency Resolution | 4 digits |
| DC Offset Range | ±10 V (into open circuit) |
| Modulation | AM, FM, VCF (Voltage Controlled Frequency) |
| Display | 4-digit LED frequency display |
| Power Supply | 115/230 V AC, 50/60 Hz |
| Operating Temperature | 0°C to 40°C |
| Model | Thandar |
|---|
