Wavetek
Wavetek / Willtek LT-8600
LAN Cable Tester
5 MHz to 8.5 GHz Frequency Range
Optical Loss Test Set (OLTS) / Fiber Optic Power Meter and Light Source Measurement Type
Up to 60 dB Dynamic Range
850 nm, 1300 nm, 1310 nm, 1550 nm Wavelengths Supported
Universal Adapter Port (SC, ST, FC, LC compatible) Connector Interface
| Attribute | Value |
|---|---|
| Frequency Range | 5 MHz to 8.5 GHz |
| Measurement Type | Optical Loss Test Set (OLTS) / Fiber Optic Power Meter and Light Source |
| Dynamic Range | Up to 60 dB |
| Wavelengths Supported | 850 nm, 1300 nm, 1310 nm, 1550 nm |
| Connector Interface | Universal Adapter Port (SC, ST, FC, LC compatible) |
| Display | LCD with backlight |
| Power Supply | Rechargeable NiMH battery pack / AC adapter |
| Battery Life | Up to 8 hours of continuous operation |
| Operating Temperature | 0°C to +50°C (32°F to 122°F) |
| Standards Compliance | TIA/EIA-526-7, TIA/EIA-526-14A, IEC 61280-4-1, IEC 61280-4-2 |
Wavetek / Willtek LT-8600 Options:
- LT-8600 - LT86SRA - Additional Remote Handset
- LT-8600 - LT8CHANNEL - Set of 2 Channel Link Adapters
- LT-8600 - LT8110 - Set of 2 110-Block Adapters
- LT-8600 - LT8IBMA - Set of 2 Token-Ring Adapters
- LT-8600 - LT8COAXA - Kit Coaxial Adapters
- LT-8600 - LT8BTCHG120 - 120V dual-bay quick battery charger
- LT-8600 - LT8BTCHG240 - 240V dual-bay quick battery charger
- LT-8600 - LT8DCCA - Deluxe hard-shell carrying case
- LT-8600 - LT8TALKSET - Set of 2 earphone/microphone headsets
- LT-8600 - LT8BATTPACK - Extra NiMH battery
- LT-8600 - LT8KIT - Professional installer's kit (Includes all of above and (2) extra batteries)
- LT-8600 - FiberKit+850 - Fiber optic cable test kit: Includes power meter and 850nm Multimode LED light source modules, ST adapters, user guide, and case
- LT-8600 - FiberKit+MM - Fiber optic cable test kit with Dual Wavelength 850nm/1300nm LED Light Source module
- LT-8600 - FiberKit+ALL - Includes all of +MM kit above, plus 1310nm and 1550nm Single-Mode laser light source modules
- LT-8600 - 542SP - Tone sensing speaker probe
| Model | LT-8600 |
|---|
The Wavetek LT-8600 tests Cat 6 up to 300MHz
