Wayne Kerr 65120P
| Attribute | Value |
|---|---|
| Frequency Range | 20 Hz to 120 MHz |
| Measurement Parameters | Z, Y, R, X, G, B, L, C, D, Q, θ, |Z|, |Y| |
| Basic Accuracy | 0.05% |
| Test Signal Level (Voltage) | 5 mV to 1 V RMS |
| Test Signal Level (Current) | 200 µA to 20 mA RMS |
| DC Bias Voltage | 0 to ±40 V (internal), up to ±200 V (external) |
| DC Bias Current | 0 to ±100 mA (internal) |
| Impedance Range | 1 mΩ to 100 MΩ |
| Interface/Connectivity | USB, LAN, GPIB (IEEE-488) |
| Display | 7-inch TFT color LCD touchscreen |
Wayne Kerr 65120P Options:
- 65120P - /B1 - Bin handler (non-isolated 5V), 25-way D-type connector, 10 bins with absolute and percentage limits
- 65120P - /B2 - Bin handler (isolated 24V), 25-way D-type connector, 10 bins with absolute and percentage limits
- 65120P - /D1 - DC Bias (0 to +40V, 0 to +100mA)
- 65120P - /D2 - DC Bias (-40V to +40V)
| Model | 65120P |
|---|
The Wayne-Kerr 65120P is an advanced programmable LCR meter designed to enhance automated testing with superior accuracy. Building upon the 65120B, it offers programmable automation that streamlines repetitive processes while maintaining high reliability. Its fast operation makes it ideal for high-throughput environments, while flexible setup options allow it to handle complex testing requirements efficiently. With its precise LCR measurement capabilities, this instrument is an excellent choice for engineers working on large-scale production testing.
Engineers benefit from the Wayne-Kerr 65120P’s ability to improve productivity in demanding test environments, offering consistent performance and adaptability across multiple applications. Its programmable features make it highly suitable for automated production lines and specialized testing needs.
Testwall can supply the used Wayne-Kerr 65120P, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Wayne-Kerr 65120P
