Wayne Kerr 6515B
| Attribute | Value |
|---|---|
| Measurement Parameters | Inductance (L), Capacitance (C), Resistance (R), Impedance (Z), Phase Angle (θ), Dissipation Factor (D), Quality Factor (Q) |
| Frequency Range | 20 Hz to 500 kHz |
| Test Signal Level | 5 mV to 1 V RMS (adjustable) |
| Basic Measurement Accuracy | 0.05% |
| Display | Dual 6-digit LCD display with backlight |
| Measurement Speed | Fast, Medium, and Slow measurement modes |
| Interface / Connectivity | IEEE-488 (GPIB) and RS-232 interfaces for remote control and data transfer |
| DC Bias | Internal DC bias up to 2 V; supports external DC bias |
| Equivalent Circuit Modes | Series and Parallel equivalent circuit modes |
| Power Requirements | 90–264 V AC, 47–63 Hz, approximately 30 VA |
Wayne Kerr 6515B 20Hz To 15MHz LCR Meter Options:
- 6515B - B1 - Bin Handler (Non-Isolated)
- 6515B - B2 - Bin Handler (Isolated 24V)
- 6515B - D1 - Dc Bias (0 To +40V, 0 To +100Ma)
- 6515B - D2 - Dc Bias (-40V To +40V)
- 6515B - E - Equivalent Circuit Analysis
- 6515B - K - Material Test
- 6515B - M - Multi-Measurement Mode
- 6515B - Y - Polar Complex Plots
| Model | 6515B |
|---|
The Wayne Kerr 6515B 20Hz To 15MHz LCR Meter offers precision impedance measurements across a frequency range of 20Hz to 15MHz. It provides accurate L, C, and R parameter readings with multiple test signal levels and measurement speeds, ensuring flexibility for both research and production environments. Its high resolution and stability make it ideal for detailed component analysis.
Engineered for electronics testing, the Wayne Kerr 6515B supports a wide variety of components, from inductors to capacitors, with quick setup and easy operation. It ensures dependable results in laboratory and manufacturing settings.
Testwall can supply the used Wayne Kerr 6515B 20Hz To 15MHz LCR Meter, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Wayne Kerr 6515B 20Hz To 15MHz LCR Meter.
