Wayne Kerr 6520B
| Attribute | Value |
|---|---|
| Frequency Range | 20 Hz to 20 kHz |
| Measurement Parameters | L, C, R, Z, D, Q, θ, G, B, X, Rp, Rs |
| Basic Accuracy | 0.1% |
| Test Signal Level | 0.1 V to 1.0 V RMS (adjustable) |
| Display | Dual 4.5-digit LCD display |
| Measurement Speed | Fast, Medium, and Slow measurement modes |
| DC Bias | Internal DC bias up to 2 V |
| Interface | IEEE-488 (GPIB) and RS-232 interfaces |
| Component Handler Interface | Built-in handler interface for automated component sorting |
| Power Supply | 90–264 V AC, 47–63 Hz |
Wayne Kerr 6520B Options:
- 6520B - /B1 - Bin handler (non-isolated 5V), 25-way D-type connector, 10 bins with absolute or percentage limits
- 6520B - /B2 - Bin handler (isolated 24V), 25-way D-type connector, 10 bins with absolute or percentage limits
- 6520B - /D1 - DC Bias (0 to +40V, 0 to +100mA)
- 6520B - /D2 - DC Bias (-40V to +40V)
- 6520B - /E - Equivalent Circuit Analysis firmware option
- 6520B - /K - Material Test firmware option (Calculates Complex Relative Permittivity and Complex Permeability)
- 6520B - /M - Multi-Measurement Mode firmware option
- 6520B - /Y - Polar Complex Plots firmware option
| Model | 6520B |
|---|
The Wayne-Kerr 6520B delivers versatile measurement capabilities for passive components, offering wide test conditions with reliable accuracy. Its compact design integrates powerful features, ensuring stable results across frequencies and clear data presentation through a high-resolution display.
Designed for both small laboratories and production environments, the 6520B provides flexibility, precision, and ease of use, making it an efficient solution for consistent component analysis.
Testwall can supply the used Wayne-Kerr 6520B, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Wayne-Kerr 6520B.
