Xantrex XDC300-20
| Attribute | Value |
|---|---|
| Output Voltage | 0 - 300 V DC |
| Output Current | 0 - 20 A |
| Output Power | 6000 W (6 kW) |
| Input Voltage | 208/240 V AC, Single Phase |
| Input Frequency | 47 - 63 Hz |
| Line Regulation | 0.01% of full scale |
| Load Regulation | 0.01% of full scale |
| Programming Interface | RS-232, GPIB (IEEE-488), Analog |
| Operating Temperature | 0°C to 50°C (32°F to 122°F) |
| Form Factor | Rack Mountable, 3U |
Xantrex XDC300-20 Options:
- XDC300-20 - GPIB - GPIB interface card (488.2 with SCPI)
- XDC300-20 - CANbus - CANbus communications link
- XDC300-20 - HV - High voltage input: 3Ø 342-500 VAC HV input
- XDC300-20 - GPIB-MC - GPIB-multichannel
| Model | XDC300-20 |
|---|
The Xantrex XDC300-20 delivers precise performance with an output of 300 V at 20 A, featuring low ripple, high stability, and dependable functionality. Its compact programmable design supports flexible constant voltage/current modes and advanced monitoring with accurate readouts of voltage and current. Engineered for demanding laboratory and industrial test conditions, it ensures reliable operation in controlled high-voltage applications.
Ideal for aerospace, energy, and research sectors, the XDC300-20 supports automated testing and comprehensive safety protections. Its robust digital controls make it a versatile solution for precision power requirements.
Testwall can supply the used Xantrex XDC300-20, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Xantrex XDC300-20.
