Yokogawa
Yokogawa 96001
AC Current Clamp, 20 Hz - 20 kHz 400 A AC
Clamp-On Power Meter / Wattmeter Function
Voltage, Current, Power (W), Power Factor, Frequency, VA, VAR Measurement Parameters
Up to 600V AC Voltage Measurement Range
Up to 1000A AC (via clamp sensor) Current Measurement Range
40 Hz to 70 Hz Frequency Range
| Attribute | Value |
|---|---|
| Function | Clamp-On Power Meter / Wattmeter |
| Measurement Parameters | Voltage, Current, Power (W), Power Factor, Frequency, VA, VAR |
| Voltage Measurement Range | Up to 600V AC |
| Current Measurement Range | Up to 1000A AC (via clamp sensor) |
| Frequency Range | 40 Hz to 70 Hz |
| Display | Digital LCD Display with simultaneous multi-parameter readout |
| Power Supply | Battery Operated (AA batteries) |
| Safety Rating | CAT III 600V |
| Accuracy | ±2% of reading (power measurement) |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Model | 96001 |
|---|
The Yokogawa 96001 Clamp-On Probe features: Compact and light with high-performance 20 Hz to 20 kHz wide frequency characteristics Can be connected to a digital multimeter Need not be connected to a power source Fit to waveform measurement using Oscilloscopes and oscillographic recorders Specifications of the Yokogawa 96001 Cur Clamp include: Measuring Range: 0 to 400 A ACrms (600 A peak) Output Voltage: 0 to 4 V ACrms (10mV/A) Accuracy (at 23 deg.C ±5 deg.C,sine wave input) Temperature Coefficient: 0.05% fs/deg.C in a range of 0 deg.C to 18 deg.C and 28 deg.C to 50 deg.C Output Impedance: Approximately 30O Load Impedance: 100kO min.//100 pF max. Effect of external magnetic field: 2mV(0.2A)or less at 400A/m Voltage of circuit under measurement: 600V ACrms maximum Diameter of applicable conductor: Maximum diameter of 33 mm Operating temperature and humidity limits: 0 deg.C to 50 deg.C, 80% RH max.(non-condensing) Storage temperature limits: -20 deg.C to 60 deg.C (non-condensing) Withstanding Voltage: 3.7kV AC for one minute (core and case, and core and output terminals) Safety Conforms to: IEC 1010 External Dimensions: Approximately 70(W) x 130(H) x 30(D)mm Weight: Approximately 220g Output cord length: Approximately 2.5 meters(with banana plug) (amplitude): ±1.5% of rdg ±0.4mV (20Hz to 40Hz) (amplitude) ±1.0% of rdg ±0.2mV (40Hz to 1kHz) (amplitude) ±(0.8 + 0.2 x f kHz)% of rdg ±(0.2 + 0.04 x f kHz)mV (1 to 20kHz) (phase) Within ±3.0 deg.C (40Hz to 1kHz)
- (amplitude): ±1.5% of rdg ±0.4mV (20Hz to 40Hz)
- (amplitude) ±1.0% of rdg ±0.2mV (40Hz to 1kHz)
- (amplitude) ±(0.8 + 0.2 x f kHz)% of rdg ±(0.2 + 0.04 x f kHz)mV (1 to 20kHz)
- (phase) Within ±3.0 deg.C (40Hz to 1kHz)
