Acterna JDSU HA9
| Attribute | Value |
|---|---|
| Device Type | Handheld Optical Attenuator |
| Attenuation Range | 0 to 60 dB |
| Wavelength Range | 1200 to 1650 nm |
| Connector Type | Universal Fiber Optic Connector Interface |
| Attenuation Accuracy | ±0.5 dB |
| Return Loss | Greater than 40 dB |
| Insertion Loss | Less than 3 dB |
| Operating Temperature | 0°C to 50°C (32°F to 122°F) |
| Storage Temperature | -20°C to 70°C (-4°F to 158°F) |
| Power Handling | Up to 300 mW (24.8 dBm) |
Acterna JDSU HA9 Options:
- HA9 - 1 - Fiber type 50/125 µm (HA9 and HA9W only)
- HA9 - 2 - Fiber type 62.5/125 µm (HA9 and HA9W only)
- HA9 - 7 - Fiber type 9/125 µm
- HA9 - 0 - No built-in options
- HA9 - 1 - Built-in 50/50 coupler (HA1 and HA9 only)
- HA9 - 4 - Built-in 2/98 coupler (HA1 and HA9 only)
- HA9 - 5 - Built-in 30/70 coupler (HA1 and HA9 only)
- HA9 - 8 - Built-in 1:2 switch (HA1 and HA9 only)
- HA9 - 9 - Built-in 10/90 coupler (HA1 and HA9 only)
- HA9 - K - Standard return loss
- HA9 - A - Analog return loss
- HA9 - 1 - Port type: Bulkheads on front
- HA9 - 2 - Port type: Bulkheads on back
- HA9 - 3 - Port type: Pigtails on front
- HA9 - 4 - Port type: Pigtails on back
- HA9 - NC - Connector type: No connector
- HA9 - FP - Connector type: FC/PC
- HA9 - FA - Connector type: FC/APC
- HA9 - SC - Connector type: SC/PC
- HA9 - SU - Connector type: SC/APC
- HA9 - SP - Connector type: ST/PC
| Model | HA9 |
|---|
The Acterna JDSU HA9 is a handheld optical attenuator designed for precision fiber optic testing, delivering stable attenuation with minimal signal distortion. Its low insertion loss design ensures dependable signal management, making it suitable for both laboratory and field use. Engineered with durability and portability, it supports technicians in achieving reliable measurements in demanding environments.
With adjustable signal power and a rugged handheld form, the Acterna JDSU HA9 guarantees accurate and repeatable results. It enables optimization of system performance across varied testing conditions while maintaining user-friendly operation.
Testwall can supply the used Acterna JDSU HA9, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Acterna JDSU HA9.
