Amplifier Research 10S4G11A
| Attribute | Value |
|---|---|
| Frequency Range | 4 GHz – 11 GHz |
| Minimum Output Power | 10 Watts CW |
| Small Signal Gain | 40 dB (minimum) |
| Gain Flatness | ±4 dB (maximum) |
| Input VSWR | 2.5:1 (maximum) |
| Output VSWR | 2.5:1 (maximum) |
| Input Connector | SMA Female |
| Output Connector | SMA Female |
| Power Requirements | 105–125 VAC / 210–250 VAC, 50/60 Hz |
| Operating Temperature | 0°C to 50°C |
| Model | 10S4G11A |
|---|
The Amplifier Research 10S4G11A is a robust RF Amplifier covering 4 to 10.6 GHz frequency range, delivering high linear performance with a gain of 40 dB and gain flatness of ±3 dB. It provides output power between 39.54 to 40.41 dBm, equivalent to 8.99 to 10.99 W, making it ideal for demanding RF and microwave applications requiring reliable power levels.
This amplifier is designed for precision testing, EMC evaluations, and signal boosting across wideband frequencies, offering stable and consistent results under rigorous operating conditions.
Testwall can supply the used Amplifier Research 10S4G11A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Amplifier Research 10S4G11A.
