Amplifier Research 150A100B
| Attribute | Value |
|---|---|
| Frequency Range | 10 kHz – 100 MHz |
| Output Power | 150 Watts (minimum) |
| Gain | 55 dB (typical) |
| Input Power for Rated Output | 0 dBm (typical) |
| Harmonics and Spurious Signals | -10 dBc (typical) |
| Input VSWR | 2.0:1 (maximum) |
| Output VSWR | Unconditionally stable into any load |
| Power Requirements | 220 VAC, 50/60 Hz, single phase |
| Cooling Method | Forced air cooling |
| Connectors | Input: Type N Female; Output: Type N Female |
| Model | 150A100B |
|---|
The Amplifier Research 150A100B RF Amplifier is a self-contained broadband amplifier, delivering 150 watts of swept power with wide instantaneous bandwidth and high gain. Its push-pull MOSFET circuitry minimizes distortion, enhances stability, and ensures safe operation into any load impedance without risk of damage.
Equipped with a front-panel digital display, the 150A100B provides status and fault monitoring, while its 8-bit RISC microprocessor offers versatile IEEE-488 (GPIB) and RS-232 interfaces for full local and remote control.
Testwall can supply the used Amplifier Research 150A100B RF Amplifier, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Amplifier Research 150A100B RF Amplifier.
