Anritsu
Anritsu 3654B
V Connector Calibration Kit, 10 MHz - 70 GHz
DC to 18 GHz Frequency Range
Type-N (m) Connector Type
1.25 max VSWR
50 Ohm Impedance
1 W average Power Rating
| Attribute | Value |
|---|---|
| Frequency Range | DC to 18 GHz |
| Connector Type | Type-N (m) |
| VSWR | 1.25 max |
| Impedance | 50 Ohm |
| Power Rating | 1 W average |
| Termination Type | Precision RF Termination / Load |
| Return Loss | 18 dB min |
| Operating Temperature | -54°C to +125°C |
| Body Material | Stainless Steel |
| Calibration Standard | Compatible with Anritsu Vector Network Analyzer calibration kits |
Anritsu 3654B Options:
- 3654B - Option 1 - Adds sliding terminations (17KF50 Female Sliding Termination, 17K50 Male Sliding Termination, 01-212 Female Flush Short, 01-211 Male Flush Short)
| Model | 3654B |
|---|
The Anritsu 3654B Calibration Kit is designed for 12-term error-corrected measurements, featuring components for both male and female ports. It supports calibration with opens, shorts, and broadband loads, and Option 1 includes sliding loads.
This kit is essential for precise VNA or VNMS calibration and is compatible with various connector styles for versatile test setups.
Testwall can supply the used Anritsu 3654B, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Anritsu 3654B.
