Keysight (Agilent) U2331A
| Attribute | Value |
|---|---|
| Number of Channels | 64 single-ended / 32 differential analog input channels |
| Sampling Rate | Up to 3 MS/s aggregate sampling rate |
| Resolution | 16-bit analog-to-digital converter (ADC) |
| Input Voltage Range | ±10 V, ±5 V, ±2.5 V, ±1.25 V (software selectable per channel) |
| Interface | USB 2.0 high-speed interface |
| Digital I/O | 8 bidirectional digital I/O lines (TTL compatible) |
| Trigger Source | Software trigger, external digital trigger, and analog trigger |
| Operating Temperature | 0 °C to 55 °C |
| Power Supply | USB bus powered, no external power supply required |
| Software Compatibility | Compatible with Keysight VEE, MATLAB, LabVIEW, and IVI-COM/C drivers |
Keysight (Agilent) U2331A Options:
- U2331A - U2802A - 31-Channel Thermocouple Input Device
- U2331A - U2901A - Terminal block and SCSI-II 68-pin connector with 1-meter cable
- U2331A - U2902A - Terminal block and SCSI-II 68-pin connector with 2-meter cable
| Model | U2331A |
|---|
The Keysight (Agilent) U2331A is a 64-channel USB multifunction data acquisition unit with 12-bit resolution and a sampling rate of up to 1MSa/s. It offers 64SE/32DI analogue inputs, 2 analogue outputs, 24-bit digital I/Os, and 2 general-purpose counter channels.
It supports polling and continuous mode for applications like multimeter operations, scope-like measurements, waveform generation, and closed-loop control, ideal for validation and production testing.
Testwall can supply the used Keysight (Agilent) U2331A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) U2331A.
