Anritsu 37247A
| Attribute | Value |
|---|---|
| Frequency Range | 40 MHz to 20 GHz |
| Instrument Type | Vector Network Analyzer (VNA) |
| Number of Ports | 2-Port |
| Dynamic Range | Up to 100 dB |
| Output Power Range | -20 dBm to +10 dBm |
| Connector Type | 3.5 mm (APC-3.5) |
| Measurement Parameters | S-Parameters (S11, S21, S12, S22), Impedance, Admittance, Group Delay |
| IF Bandwidth | 10 Hz to 30 kHz |
| Number of Data Points | Up to 1601 points per sweep |
| Display | Color CRT Display with multiple trace formats including Log Magnitude, Phase, Smith Chart, and Polar |
Anritsu 37247A Options:
- 37247A - Option 1 - Rack Mounting (track slides with 90° tilt capability, mounting ears, and front panel handles for standard 19-inch equipment rack)
- 37247A - Option 1A - Rack Mounting (mounting ears and hardware to permanently mount instrument in a standard 19-inch equipment rack)
- 37247A - Option 2A - High Speed Time (Distance) Domain Measurement Capability
- 37247A - Option 4 - External SCSI-2 Hard Disk Drive Compatibility (provides SCSI-2 rear panel connector; removes internal HDD)
- 37247A - Option 7A - Universal Test Port Configuration: Universal/GPC-7
- 37247A - Option 7N - Universal Test Port Configuration: Universal/N, male
- 37247A - Option 7NF - Universal Test Port Configuration: Universal/N, female
- 37247A - Option 7S - Universal Test Port Configuration: Universal/3.5 mm, male
- 37247A - Option 10A - High Stability Time Base and 1 Hz Frequency Resolution
- 37247A - Option 11 - Reference Loop Extension Cables (provides access to the a1 sampler RF input)
- 37247A - Option ES 31 - 3 Year On-Site Repair
- 37247A - Option ES 37 - 3 Year On-Site Verification
- 37247A - Option ES 38 - 3 Year On-Site Mil-Std Verification
- 37247A - Option ES 51 - 5 Year On-Site Repair
| Model | 37247A |
|---|
The Anritsu 37247A Network Analyzer covers 40 MHz to 20 GHz, providing precise measurement of complex transmission and reflection characteristics in two-port devices. It features dual source control, tune mode, LabVIEW compatibility, six independent markers, Smith chart, trace overlay, autoscale, and a 7.5" VGA color display. Users benefit from LOG/Phase/LIN magnitude display and a four-channel system with trace memory.
Ideal for laboratory and production environments, the Anritsu 37247A enables accurate amplitude and phase measurements with rapid frequency sweeps. Its versatility makes it suitable for advanced RF and microwave component analysis.
Testwall can supply the used Anritsu 37247A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Anritsu 37247A.
