Anritsu 37369A
| Attribute | Value |
|---|---|
| Frequency Range | 40 MHz to 40 GHz |
| Dynamic Range | Up to 100 dB |
| Output Power Range | -10 dBm to +10 dBm |
| Measurement Parameters | S11, S21, S12, S22 (Full 2-Port S-Parameters) |
| Connector Type | 2.4 mm (male) test port connectors |
| Trace Noise | Less than 0.005 dB RMS |
| Number of Data Points | Up to 1601 points per sweep |
| IF Bandwidth | 1 Hz to 30 kHz |
| Sweep Time | 50 ms minimum (401 points) |
| Interface/Connectivity | GPIB (IEEE-488), RS-232, and parallel port interfaces |
Anritsu 37369A Options:
- 37369A - Option 1 - Rack Mounting: Rack mount kit containing a set of track slides (90 tilt capability), mounting ears, and front panel handles to let the instrument be mounted in a standard 19-inch equipment rack
- 37369A - Option 1A - Rack Mounting: Rack mounting kit containing a set of mounting ears and hardware to permanently mount instrument in a standard 19-inch equipment rack
- 37369A - Option 2 - High Speed Time (Distance) Domain Measurement Capability
- 37369A - Option 4 - External SCSI-2 Hard Disk Drive Compatibility: Provides SCSI-2 rear panel connector for connection of an external SCSI HDD, removes internal HDD
- 37369A - Option 7A - Universal Test Port Configuration Replaces Universal/K Connector with Universal/GPC-7
- 37369A - Option 7N - Universal Test Port Configuration Replaces Universal/K Connector with Universal/N, male
- 37369A - Option 7NF - Universal Test Port Configuration Replaces Universal/K Connector with Universal/N, female
- 37369A - Option 7S - Universal Test Port Configuration Replaces Universal/K Connector with Universal/3.5 mm, male
- 37369A - Option 10 - High Stability Time Base: Replaces the standard temperature compensated crystal oscillator with an ovenized crystal oscillator
- 37369A - Option 10A - High Stability Time Base (adds 1 Hz frequency resolution)
- 37369A - Option ES 31 - 3 year on-site repair
- 37369A - Option ES 37 - 3 year on-site verification
- 37369A - Option ES 38 - 3 year on-site Mil-Std verification
- 37369A - Option ES 51 - 5 year on-site repair
| Model | 37369A |
|---|
The Anritsu 37369A Network Analyzer combines a synthesized source, S‑parameter test set, and tuned receiver in one compact unit. It delivers precise measurements from 40 MHz to 40 GHz with a fast sweeping synthesized source, auto reversing test set, solid‑state transfer switch, and four independent display channels. Its built‑in hard and floppy disk drives ensure efficient data handling, while advanced calibration options such as LRL/LRM and adapter removal calibration provide accuracy in demanding RF applications.
Engineered for bench‑top testing, the Anritsu 37369A ensures fast measurement throughput via GPIB, supporting high‑speed automation. With its multi‑channel receiver and versatile display capability, it offers reliable performance across a broad frequency range.
Testwall can supply the used Anritsu 37369A Network Analyzer, fully tested. With expert support and global delivery, Testwall ensures high‑performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Anritsu 37369A Network Analyzer.
